CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging
CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging
CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging
CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging
Specifications
Brand Name :
GDHY
Model Number :
CBB22 154J630V P10
Certification :
SGS,ISO
Place of Origin :
GUANGZHOU, CHINA
MOQ :
100KPCS
Price :
PLEASE CONTACT US FOR MORE DETAILS
Payment Terms :
Western Union, T/T, MoneyGram
Supply Ability :
1KK PCS/MONTH
Delivery Time :
15 WORKING DAYS
Packaging Details :
PLASTIC BAG
SUPPLIER TYPE :
ORIGINAL MANUFACTURER
TYPE :
METALLIZED POLYPROPYLENE FILM CAPACITOR
DIMENSION :
13.0*7.5*12.0MM
CAPACITANCE :
0.15UF
RATED VOLTAGE :
630V
PITCH :
10MM
APPLICATION :
DC,AC,PULSE CIRCUITS
ENCAPSULATION :
POWDER
Description

CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging150NF 630VDC CBB22 METALLIZED POLYPROPYLENE FILM CAPACITOR PITCH10

Technical Parameter

Reference Standards GB/T 10190(IEC 60384-16)
Climate Category 40/085/21
Operating Temperature Range Max 85℃
Capacity Range 0.15μF
Rated Voltage 630VDC
Capacity Tolerance ±5%(J);±10%(K)
Withstand voltage Vt-t:1.6UN 5S (at20 ±5%)
Dissipation Factor tgδ≤0.0010 (20℃, 1KHz)
Maximum Pulse Rise Time (dv/dt) 320(V/μS)
Insulation Resistance

C≤0.33μF R≥30000MΩ (at20℃ 100VDC 1Min)

Specification download: CBB22.pdf

Application

Can also used in Electric tool, Color TV, Wireless joining device, Cross-power circuit.

Widely used in High frequency, DC, AC, Pulse Circuits, and the S-correction circuits of the display device.

Feature

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy powder coating

● Good self-healing

● Resistance to high voltage, small tgδ, low temperature rise

Product Picture

CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk PackagingCBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging

Product Shape

CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging

Production

CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging

Workshop&Equipment

CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging

Packing method

CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging

Certificate

CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging

Exhibition

CBB22 150nf 630V P10 Polypropylene Film Capacitor Wholesale Bulk Packaging
