Kapasitor Polypropylene Film Capacitor 0.82uF 824J 400V CBB22 LED Lighting Circuit Board
Kapasitor Polypropylene Film Capacitor 0.82uF 824J 400V CBB22 LED Lighting Circuit Board
Specifications
Brand Name :
GDHY
Model Number :
CBB22 824J400V P20
Certification :
SGS,ISO
Place of Origin :
GUANGZHOU, CHINA
MOQ :
100KPCS
Price :
PLEASE CONTACT US FOR MORE DETAILS
Payment Terms :
Western Union, T/T, MoneyGram
Supply Ability :
1KK PCS/MONTH
Delivery Time :
15 WORKING DAYS
Packaging Details :
PLASTIC BAG
DIELECTRIC :
METALLIZED POLYPROPYLENE FILM
CAPACITANCE :
0.82UF/824
RATED VOLTAGE :
400V
DIMENSION :
23*8.5*15mm
PITCH :
20MM
ENCAPSULATION :
FLAME RETARDANT EPOXY RESIN POWDER
Description

Kapasitor Polypropylene Film Capacitor 0.82uF 824J 400V CBB22 LED Lighting Circuit Board0.82UF 400V CBB22 METALLIZED POLYPROPYLENE FILM CAPACITOR P20 AUDIO INDUSTRY LIGHTING POWER

Technical Parameter

Model number B8240400-D-20-1R
Reference Standards GB/T 10190(IEC 60384-16)
Climate Category 40/085/21
Operating Temperature Range from -40℃ to +85℃
Capacity Range 0.82μF
Rated Voltage 400V
Capacity Tolerance ±5%(J);±10%(K)
Withstand voltage Vt-t:1.6UN 5S (at20 ±5%)
Dissipation Factor tgδ≤0.0010 (20℃, 1KHz)
Maximum Pulse Rise Time (dv/dt) 180(V/μS)
Insulation Resistance RCN≥30000S (at20℃ 100VDC 1Min)

Specification download: CBB22.pdf

Application

Widely used in High frequency, DC, AC, Pulse Circuits, and the S-correction circuits of the display device.

Suitable for Lighting industry, Audio industry, Automation industry, Power industry, Household appliance, Telecommunication industry.

Feature

● Non-inductive winding structure

● Good stability and reliability, high insulation resistance

● Good self-healing

● Resistance to high voltage, small tgδ, low temperature rise

Product Picture
