Red 0.33UF 334J 630V CBB Polypropylene Film Capacitor P20 Self Healing

Specifications

Brand Name :

GDHY

Model Number :

CBB22 334J630V P20

Certification :

SGS,ISO

Place of Origin :

GUANGZHOU, CHINA

MOQ :

100KPCS

Price :

PLEASE CONTACT US FOR MORE DETAILS

Payment Terms :

Western Union, T/T, MoneyGram

Supply Ability :

1KK PCS/MONTH

Delivery Time :

15 WORKING DAYS

Packaging Details :

PLASTIC BAG

BRAND :

GDHY

SUPPLIER TYPE :

ORIGINAL MANUFACTURER

PRODUCT TYPE :

CBB POLYPROPYLENE FILM CAPACITOR

DIELECTRIC :

METALLIZED POLYROPYLENE FILM DIELECTRIC

CAPACITANCE :

0.33UF/334

RATED VOLTAGE :

630VDC

DIMENSION :

18.0*8.0*13.0MM

PITCH :

20MM

Description

Red 0.33UF 334J 630V CBB Polypropylene Film Capacitor P20 Self Healing 0.33UF 334J630V P20MM CBB22 POLYPROPYLENE FILM CAPACITOR SOUND EQUIPMENT AUDIO-VISUAL DEVICES

Technical Parameter

Brand name	GDHY
Model number	B3340630-D-20-1U
Capacity Range	0.33μF/334
Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	from -40℃ to +85℃
Rated Voltage	100VDC/250VDC/400VDC/630VDC
Capacity Tolerance	±5%(J);±10%(K)
Withstand voltage	Vt-t:1.6UN 5S (at20 ±5%)
Dissipation Factor	tgδ≤0.0010 (20℃, 1KHz)
Maximum Pulse Rise Time (dv/dt)	240(V/μS)
Insulation Resistance	R≥100000MΩ (at20℃ 100VDC 1Min)

Specification download: CBB22.pdf

Application

● This product is suitable for high frequency, DC, AC, pulse circuits, and S-correction circuits of the display device.

● It is widely used in display, sound equipments, audio-visual devices, telecommunication equipment, data transmission and process facility and various electronic equipment, such as electric mosquito swatter, buffer, transfer switch, high voltage power supply, electronic ballast.

Feature

● Non-inductive winding construction, epoxy resin to seal

● Metallized polypropylene film dielectric, radial CP wire

● Good stability and reliability, excellent insulation resistance property.

● Good self-healing

● Resistance to high voltage, small dissipation factor at high-frequency, and small internal temperature rise

Product Picture
