CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption
CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption
CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption
CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption
Specifications
Brand Name :
GDHY
Model Number :
CBB22-104J630V-15RN-1R
Certification :
SGS,ISO
Place of Origin :
GUANGZHOU, CHINA
MOQ :
10KPCS
Price :
0.1 USD/ PCS
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
1000 KPCS
Delivery Time :
14 DAYS
Packaging Details :
plastic bag and carton
Supplier Type :
ORIGINAL MANUFACTURER
Type :
POLYPROPYLENE FILM CAPACITOR
Model number :
B1040630-D-15-1R
material :
Metallized polypropylene film
Operating Temperature Range :
-40℃～85℃
Capacitance :
0.1UF
Capacity Tolerance :
±5%
Rated DC Voltage :
630VDC
Pitch :
10±1.5mm
height :
8mm
width :
13mm
thickness :
12.5mm
Description

CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric AbsorptionCBB22 104J630VDC ,very low dielectric absorption,Polypropylene Film Capacitor

Technical Parameter

Reference Standards GB/T 10190(IEC 60384-16)
Climate Category 40/085/21
Operating Temperature Range -40°℃~85°℃
Capacity Range 0.1μF
Rated Voltage 630VDC
Capacity Tolerance ±5%
Withstand voltage Vtet:1.6UN 5S (at20±5℃)
Insulation Resistance

C≤0.33uF R≥100000MQ(at20°℃ 100VDC 1Min)

C>0.33 uF RCN≥30000s (at20℃ 100VDC 1Min)

Specification download: CBB22.pdf

Application

Widely used in High Frequency, DC, AC, Pulse Circuits. S-correction circuits of the display device

Features

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy resin powder encapsulation

● Resistance to high voltage, small tg6,low temperature rise

Product picture

CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric AbsorptionCBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption

Product shape

CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption

Production

CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption

Workshop& Equipment

CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption

Packing method

CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption

Certificate

CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption

Exhibition

CBB22 104J630VDC Polypropylene Film Capacitor Very Low Dielectric Absorption
