1uF 251nF Axial Audio Grade Film Capacitor Metallized Polypropylene 250VDC CBB20

Specifications

Brand Name :

GDHY

Model Number :

CBB20 251106J250

Certification :

SGS,ISO

Place of Origin :

GUANGZHOU,CHINA

MOQ :

30KPCS

Price :

0.1 USD/ PCS

Payment Terms :

Western Union, MoneyGram, T/T

Supply Ability :

1000 KPCS/ MONTH

Delivery Time :

14 DAYS

Packaging Details :

CARTON

TYPE :

polypropylene film capacitor

PLACE OF ORIGIN :

GUANGZHOU,CHINA

SUPPLIER TYPE :

Original manufacturer

Terminal :

Axial leads

MODEL :

CBB20 251106J250

MATERIAL :

Thin film is used as electrolyte, epoxy resin potting

CHARACTERISTICS :

Thin film is used as electrolyte, epoxy resin potting, good self-healing, high reliability, low loss, superior electrical performance, mainly used for high-frequency filtering, and crossover, and is used in communication and industrial power supply equipme

OPERATION TEMPERATURE :

-40℃～85℃

APPLICATION :

It is widely used in filtering, noise reduction, and low-pulse circuits to suppress loop compensation coupling, frequency division, and bypass filter resonance start

RATED DC VOLTAGE :

250VDC,400VDC,630VDC

COLOR :

YELLOW

LENGTH :

38MM

ENCAPSULATION :

Flame retardant epoxy resin powder encapsulation

TOLERANCE :

±5;%±10%;±20%

CAPACITANCE :

106nF

CERTIFICATION :

CQC, KC, VDE, SGS

DIMENSION :

20.5MM，length 38mm

Media Available :

datasheet, Photo

Description

1uF 251nF Axial Audio Grade Film Capacitor Metallized Polypropylene 250VDC CBB20

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃~85℃,Tmax 105℃
Capacity Range	0.01uf-40uf
Rated Voltage	100VDC,250VDC,400VDC,630VDC
Capacity Tolerance	±5%(J);±10%(K);±20%(m)
Withstand voltage	Vt-t:1.75Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 1000VDC;25℃ ±5℃,60s

Application

It is widely used in filtering, noise reduction, and low-pulse circuits to suppress loop compensation coupling, frequency division, and bypass filter resonance start.
Often used in displays, power supplies, energy-saving lamps, program-
controlled switches, speakers, audio amplifiers, instruments, etc.
Circuits and electronic devices that generate electromagnetic interference from power sources

Features

This capacitor uses metal-plated PP & PE
Thin film is used as electrolyte, epoxy resin potting, good self-healing, high reliability, low loss, superior electrical performance, mainly used for high-frequency filtering, and crossover, and is used in communication and industrial power supply equipment.

Product picture
