High Speed Auto Electrode Punching Machine Cutter Disc Battery Production Line
High Speed Auto Electrode Punching Machine Cutter Disc Battery Production Line
Specifications
Brand Name :
GELON
Model Number :
GN-S300P
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD 93000 / set
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
50 sets / month
Delivery Time :
30~45 days
Packaging Details :
Wood frame
Standard Cutting Die :
1 pc （Customized）
Punching Size :
Max. L60*W60mm
Punching Force :
Max. 1T（1MPa compress air)
Punching stroke :
12mm
Cutter Life cycle :
10,000 times
Punching thickness :
Max. 0.5mm
Punching accuracy :
±0.1mm
Air Source :
0.6-1MPa compress air
Power :
3000W
Size :
L2000mm*W1000mm*H1800mm
Weight :
About 1000Kg
Description

High Speed Auto Electrode Punching Machine Cutter Disc Battery Production Line

I.Introduction

1. The automatic electrode punching machine is a kind of equipment cutting the cathode and anode electrode of lithium-ion batteries. The equipment adopts pneumatic method , to carry out single die punching electrode, and can provide various shapes of dies, according to customer requirements. So as to realize the molding and punching of different sizes of electrode . After the electrode is fed, and it will punching by cutting die.

  • Drive by cylinder , punching force and speed could be adjustable ; High strength frame, upper and lower precision pressing plates, high-performance tools, ensuring die cutting accuracy; The die-cut products have small burr, no powder falling, no indentation and other poor appearance; It is equipped with a set of standard cathode and anode cutting dies as standard, also can be customized; The drawer design of the upper and lower punching dies ensures safe operation.

3. Process : roll feeding - automatic deviation correction - automatic tension - automatic punching - receiving .

II. Technologic effects

High Speed Auto Electrode Punching Machine Cutter Disc Battery Production Line

III.Parameter

Item Description Remark
Standard Cutting Die 1 pc Customized
Punching Size Max. L60*W60mm
Punching Force Max. 1T(1MPa compress air) Recommended regulating pressure: 500kg (0.5MPa)
Punching stroke 12mm Distance between cutter die and blanking plate
Cutter Life cycle 10,000 times
Punching thickness Max. 0.5mm Al / Cu foil as basic material
Punching accuracy ±0.1mm
Air Source 0.6-1MPa compress air
Power 3000W
Size L2000mm*W1000mm*H1800mm
Weight About 1000Kg
