Aluminium Laminated Film Pouch Cell Case Forming Machine Automatic Formation Machine
Aluminium Laminated Film Pouch Cell Case Forming Machine Automatic Formation Machine
Specifications
Brand Name :
GELON
Model Number :
GN-S350F
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
US 1000-50000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10 set per month
Delivery Time :
5-15 sky
Packaging Details :
wooden box custom
Production Name :
pouch cell case aluminum laminated film forming/punching machine
Warranty :
1 Year
Applicable area of aluminum plastic film :
Max. 600 x 500mm
Thickness of the aluminum plastic film :
0.11-0.2mm
Stamping depth :
Single ﹤ 6mm
Productivity :
200-450pcs/H
Gas-liquid pressurized cylinder :
10T(made in taiwan)
Applicable mold :
three-plate mold / spring mold
Power :
AC110V 5KW
Air source :
06-0.7Mpa 40L/S
Equipment dimension :
700 * 2250 * 1860mm
Weight :
870Kg
Description

Automatic Formation Machine Aluminium Laminated Film Pouch Forming Machine Battery Pouch Cell Case Forming

Summarization

  • Suitable for automatically stamping the aluninum laminated film for pouch cells(Li-battery cell),with reeled materials as the feeding materials;
  • Automatic feeding,step driving,and cutting at given length;
  • With touch screen(for operation),PLC control,electronic ruler,break piont detecting,and light screen safety protection;
  • Applicable dies :three-plate mold or spring mold

  • ①gas-liquid pressurized cylinder carry out high output pressure

    ②the position of the cutting blade showing by the electron ruler

    ③the feed delivery robot

    Technical parameter:

  • Item    		 CKA200I
    Applicable area of aluminum plastic film Max. 380 x 200mm
    Thickness of the aluminum plastic film 0.11-0.2mm
    stamping depth Single ﹤ 6mm
    productivity 200-450pcs/H
    Gas-liquid pressurized cylinder 10T(made in taiwan)
    applicable mold three-plate mold / spring mold
    power AC220V 05KW
    air source 06-0.7Mpa 40L/S
    equipment dimension 700 * 2250 * 1860mm
    weight 870Kg

Aluminium Laminated Film Pouch Cell Case Forming Machine Automatic Formation Machine

Aluminium Laminated Film Pouch Cell Case Forming Machine Automatic Formation Machine

Aluminium Laminated Film Pouch Cell Case Forming Machine Automatic Formation Machine
