PE / PP Separator 2325 Battery Testing Equipment Ceramic Coated Separator
PE / PP Separator 2325 Battery Testing Equipment Ceramic Coated Separator
PE / PP Separator 2325 Battery Testing Equipment Ceramic Coated Separator
PE / PP Separator 2325 Battery Testing Equipment Ceramic Coated Separator
Specifications
Brand Name :
Gelon
Model Number :
GN-PP
Certification :
CE
Place of Origin :
China
MOQ :
50 sqm
Price :
USD 50-150/Roll
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 SQM Per Month
Delivery Time :
4-6 week
Packaging Details :
Standard Packing
Porosity :
38%-44%
Thickness :
16, 18, 20, 25, 30 Micron, etc
Width :
Customerization
Technology :
From Japan, Made in China
MOQ :
50sqm
Tensile Strength :
More Than 90 MPa
Description

PE/PP Separator Ceramic Coated Separator 2325 Separator Lithium Battery Materials

Lithium battery materials--Celgard separator--Li-ion battery separator/membrane
1. Thickness: 16&18&20&25&30&40micron
2. Width: 60mm
3. MOQ: 50Sqm

Specification for 16micron thickness for reference:
TermUnitInspection value
Appearance Ivory-white
Thicknessmicron16± 2
Gas permeabilitySec/100ml350-550
Porosity%38-44
Puncturing Strengthg>300
Tensile strength MDMpa>90
Tensile strength TDMpa>100
Film close temperaturedegree≤ 135
Film break temperaturedegree≥ 147
90 degree heat shrink MD%≤ 3.5
90degreeheat shrink TD%≤ 2
105degree heat shrink MD%≤ 5
105degree heat shrink TD%≤ 3
120degree heat shrink MD%≤ 20
120degree heat shrink TD%≤ 15

Advantages:

High safety: Multilayer membrane efficiently reduces the safety hazards (crystal point, holes…) which are found as defects on single layer membrane; No TD shrinkage, , low MD shrinkage; Perfect heat resistance and anti-oxidant; High puncture strength & mechanical strength , suitable for high/low voltage system.

Good uniformity: Using popular dry & uniaxial stretching process, insure the pore sizes uniformity and well distributed on membrane. The separator has multilayer structure with better thickness uniformity to improve Li-ion battery cycle life.

Excellent air permeability: High porosity, high air-permeability, low sinuosity, suitable for high rate discharging of electric vehicle Li-ion battery.

Various products: Basic separator, Ceramic coated separator, Polymer coated separator, Multifunctional hybrid coating separator, Multi-layer functional coated separator.

PE / PP Separator 2325 Battery Testing Equipment Ceramic Coated SeparatorPE / PP Separator 2325 Battery Testing Equipment Ceramic Coated SeparatorPE / PP Separator 2325 Battery Testing Equipment Ceramic Coated SeparatorPE / PP Separator 2325 Battery Testing Equipment Ceramic Coated Separator

Thickness 16± 2micron Gas permeability Sec/100ml350-550
Porosity 38-44% Puncturing Strength >300g
Tensile strength MDMpa>90 Tensile strength TDMpa>100
Film close temperature degree≤ 135 Film break temperature degree≥ 147

PE / PP Separator 2325 Battery Testing Equipment Ceramic Coated SeparatorPE / PP Separator 2325 Battery Testing Equipment Ceramic Coated SeparatorPE / PP Separator 2325 Battery Testing Equipment Ceramic Coated SeparatorPE / PP Separator 2325 Battery Testing Equipment Ceramic Coated Separator
