Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
Specifications
Brand Name :
Gelon
Model Number :
GN-ST750
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
60000-100000USD
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
30sets per months
Delivery Time :
2months
Packaging Details :
wooden box package
Product name :
Roll to Roll Automatic Slitting Machine For Battery Electrode Slitting
Function :
Electrode slitting
Battery type :
Cylinder, Pouch, Prismatic cell
Equipment type :
full automatic
Efficiency :
high efficiency
Voltage :
380V
Width :
1-800mm
Speed :
1-100m/min
Description

Roll to Roll Automatic Slitting Machine For Battery Electrode Slitting

1.1 Introduction of principle

The rolled cathode/anode electrode is loaded into the roll mechanism, and through the power traction, the electrode is sent to the cutter set which is arranged according to the process specifications for slitting, and the upper and lower rewinding device collects the slit electrode into the roll, and the edge materials are collected by the edge material device. The equipment is assisted by the deviation correction system, tension drive system, dust suction system (including knife suction dust) and other auxiliary precision operation to ensure the stable slitting of the electrode, burr, straightness and other process indicators within the process range.

1.2 Process flow

Transfer carriage Loading the material to unwind reels→èreceived platform→èTraction roller→èSlitting knife setè→Over-roller set →èSeparately up and down sliding differential rewinding axis→èEdge material rewinding→èSet the required electrode tension→èSwitching the electrode alignment system to automatic→èPress the system to start button→èThe equipment automatically slitting and collects in rolls.

No. Item Technical parameter Remark

1

Suitable for the material

 Electrode with rolling pressed LFP,LCO,LMO,NMC,LTO,Carbon,Graphite

2

Running foil parameter

Aluminum foil(AL):thickness:9～30um; Width: 50～500mm

Roll diameter: Max.400mm

Cupper foil (Cu):thickness: 5～30um

Width:50～500mm；

Roll diameter: Max.400mm；
3 Roller width 550 mm
4 Slitting width 30~500mm
5 Mechanical operating speed 50m/min
5 Slitting speed 1-40m/min Depending on the slitting effect
7 Electrode thickness range 50-300μm

8

Slitting method

1, Combined slice knife slitting;

2, Nishimura type knife set structure.

3, Slitting specifications, 18650/21700(7 lanes,7knives /set,included Cathode and Anode slitting knives)
9 Rewinding method Two axis slip difference axis dislocation rewinding

Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine

Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine

Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine

We also provide other full automatic production line .

Electrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting MachineElectrode Slitting Battery Assembly Machine Roll to Roll Automatic Slitting Machine
