Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Specifications
Brand Name :
Gelon
Model Number :
GN-HS200
Certification :
CE
Place of Origin :
China
MOQ :
1PCS
Price :
USD1400-1800/PCS
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500pcs/month
Delivery Time :
15-30days
Packaging Details :
wooden case
PProduct name :
Pouch Cell Top&Side Heating Sealing Machine
Top Sealing times :
0-99s Adjustable
Side Sealing times :
Recommended 3~4s
Sealing thickness :
0~0.5mm
Sealing length :
190mm
Sealable battery size :
Max L180mmxW180mm(with air pocket, with tab)
Sealing width :
5mm（standard）
Description

Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment

PRODUCT FEATURE:

1)The machine can be used for different sizes batteries and can be adjusted easily by speed governing (or changing) clamps or adjusting(or changing)end cover.

2)Top and bottom end covers are drove by two cylinders, moving elastically.

3)The cover is made of copper material, having good heat effectiveness and saving electricity.

4)The pressure of top end cover can be adjusted by valve regulation.

5)The temperature of top and bottom end covers can be adjusted by temperature controller.

6)The machine has the warning function on temperature anomaly.

7)The Machine has great protective function with safety light curtain and double buttons protection.

8)The machine has PLC controller for easily operating.It's light for carrying.

9)The machine's rack is made of aluminium with good-looking.It can take manual operation while testing machine and take PLC auto-operation while bulk producing.

Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly EquipmentGelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment

Upper mould soft seal temperature Recommended 200°C
Lower mould temperature Recommended160℃-180℃
Power source AC220V/50Hz.AC110V/60Hz
Power 1800W
Equipment Size L350mm*W380mm*H520mm
Equipment weight Around 42Kg
Related Products
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Company Profile
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment
Certifications
Gelon Lab Pouch Cell Top&Side Heating Sealing Machine Heat Sealer Pouch Cell Assembly Equipment

We can supply:
1.Full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.

2.Full set of lithium battery equipments,for example:
mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.

3.Full set of lithium battery technology.
we can design the laboratory and production line,according to customer's request.
