Electrical 32KW 380V DC Load Bank IP32 With Parallel Operation Function
Electrical 32KW 380V DC Load Bank IP32 With Parallel Operation Function
Specifications
Brand Name :
Fullde
Model Number :
LB-32KW-380VDC
Certification :
CE, ISO9001
Place of Origin :
Dongguan,China
MOQ :
one set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 Sets per Month
Delivery Time :
15 working days
Packaging Details :
Wooden packaging,Carton packaging
Color :
Grey RAL7032/ Blue
Max Protection Grade :
IP32
Cooling mode :
Forced air cooling, horizontal inlet air and upwards exhaust cooling
Accessories :
Switch: ABB, Siemens and Schneider, PLC: Panasonic and Siemens;
Dimensions :
900*1200*1400
Weight :
130KG
Description

Electrical Lab 32KW DC Load Bank with 19 Steps Min Test Current 0.1A

Features:

1. Steady-state test: automatically detect 3-phase voltage, current, active power, inactive power, apparent power, power factor, frequency, run time, total energy and so on.

2. Transient-state test: according the presetted power values, can create a loading dips and drops, automatically detect the maximum and minimum values of each phase voltage, current and frequency in the dips and drops, and calculate the power & power factor in each phase.

3. Parallel operation: for the requirement of some high power test, can co-work in parallel perfectly. 4. Short circuit protection function, guarantee the test safe and stable.

Typical Applications:

1. In the acceptance inspection of load bank, the relevant department have to check whether the new devices fulfill the actual requirement.


2. After the installation of noise reduction devices, the loading capability must be test again.


3. For the routine test & maintenance, it is essential to test the output power and loading capability.

Our Services:


1. Supply professional consult.


2. Reply technical question in time


3. Give reasonable offer


4. Arrange shipment as sales contract date


5. Use best shipment way to assure the goods intact.

Specification
Rating voltage 380VDC
Max Load Power Power: 32kW
Load Resolution step:0.1A
Power Factor 0.8
Load Tolerance ±5%
Fan Control Power 110V/220V,50Hz/60Hz
Wire Connection Load bank input——Copper bar
Control power input——Connector-bar
Max Protection Grade IP32
Way of Working Continuous Working
Cooling mode Forced air cooling, horizontal inlet air and upwards exhaust cooling
Transportation Hoisting
Color RAL7032
Dimensions 900*1200*1400
Weight 130KG
Accessories Switch: ABB, Siemens and Schneider, PLC: Panasonic and Siemens;
Operating Environment Parameter
Ambient Temperature -10℃~+50℃
Relative Humidity ≤95%

Detail pictures as below:

Electrical 32KW 380V DC Load Bank IP32 With Parallel Operation Function
