IP20 Generator Neutral Grounding Resistor , 10KV High Voltage Resistor
IP20 Generator Neutral Grounding Resistor , 10KV High Voltage Resistor
IP20 Generator Neutral Grounding Resistor , 10KV High Voltage Resistor
IP20 Generator Neutral Grounding Resistor , 10KV High Voltage Resistor
Specifications
Brand Name :
Fullde
Model Number :
FD201707070
Certification :
CE, ISO9001
Place of Origin :
Dongguan,China
MOQ :
1 Set/Sets
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Set/Sets per Month
Delivery Time :
15 working days
Packaging Details :
Standard export carton or wooden box
Rated voltage :
10KV
operating time :
10s
Power frequency withstand voltage :
32KV/min
equipment :
Isolation switches, current transformers, intelligent temperature and humidity control, etc
Rated Frequency :
50Hz/60Hz
Protection Degree :
IP30(indoor)
Description

IP20-IP56 Generator Neutral Point Grouding Resistance Complete Set

Environment Condition:


1. Suitable for indoor and outdoor


2. System frequency scope: 50Hz or 60Hz


3. Altitude: Not over 3500m (Please specify when ordering because high elevation leads to poor heat
dissipation)


4. Ambient condition: -20℃~+70℃, 95%RH at the most


5. Wind pressure: Not over 700MPa (equals to wind speed of 34m/s)


6. Seismic intensity: Lower than Class VIII as demonstrated by the China Seismic Intensity Scale


7. Environmental pollution level: Class IV or lower


8. Surroundings: No flammable or explosive objects, no corrosive gas or conductive dust


9. Our neutral grounding resistor will generate heat during work, thus leading to a big temperature rise. So, there should be certain space around this electrical device during installation and operation.

Introduction of Generator Neutral Point Grouding Resistance Complete Set:


Neutral grounding resistors are composed of special stainless steel electric-heat metal imported.They are with outstanding characters such as high temperature-resistant capability,excellent anti-oxidation performance,strong tensile characteristics,high resistivety and stable resistance value,what’s more,it can sustain electric and thermodynamic performance,which enables safe and reliable operation.
According to different connection mode or various customer requests,we can provide epoxy resin to cast dry type transformers,zero sequence current transformers,single-phase disconnecting switches,heater and thermo/humidity controllers etc.
