Marine Compact Gas Powered Diesel Engine For Barge Boat And Fishing Boats
Marine Compact Gas Powered Diesel Engine For Barge Boat And Fishing Boats
Marine Compact Gas Powered Diesel Engine For Barge Boat And Fishing Boats
Marine Compact Gas Powered Diesel Engine For Barge Boat And Fishing Boats
Specifications
Place of Origin :
China
Brand Name :
GSKA
CertifiCAT-partsion :
CE/RoHs/ISO9001
Quality Standards: :
BS4999,BS5000, BSEN60034,BSEN61000,IEC60034
MOQ :
1 set
Price :
Negotiable
Packaging Details :
Standard plywood and wood package.the actual package size against genset size and handle requires.
Delivery Time :
5-6 weeks on receipt of official sales contract
Payment Terms :
L/C,D/P,D/A, Alipay, West Union, TT. Cash,Paypal
Supply Ability :
50 sets per Month
Port: :
HongKong or ShenZhen,ShangHai,Dalian as required
Model Number :
YC6112
Description

Marine Compact Gas Powered Diesel Engine For Barge Boat And Fishing Boats

Complete set of the product imported from Ford, USA;
Integral forged steel crankshaft and high-quality alloyed iron castings of the cylinder block & head are imported and characterized by compact space, smaller weight, lower vibration & noise, higher reliability with an overhaul period of more than 12000 hours;

Model
YC6112ZLC
YC6112ZLCA
YC6112ZLCB
YC6112ZLCD
Type
Vertical, in-line, water-cooled, 4-stroke
Intake way
Gas turbo-charging & inter-cooling
No. of cylinders X Bore X Stroke mm
6×112×132
Displacement L
7.8
Compression ratio
17.4:1
Continuous power /speed(kW/r/min)
160/1800
145/1800
125/1800
140/1500
One-hour power/speed(kW/r/min)
Main machine
176/1858
159.5/1858
137.5/1858
154/1548
Ancillary machine
154/1500
Min. specific fuel consumption(g/kW·h)
≤215
Specific oil consumption (g/kW·h)
≤1.5
Crankshaft rotation direction (seen from power output end)
Counterclockwise
Net weight (kg)
1000
Overall dimensions (LxWxH) (mm)
1620×839×1271
Matched reduction gearbox
120C,135,135L,MB242 etc.
SpecifiCAT-parts-partsion of connection with the gearbox
Casing:SAE1# Flywheel:14〞
Overhaul period
﹥12000 hours

Features:

l Complete set of the product imported from Ford, USA;
l Integral forged steel crankshaft and high-quality alloyed iron castings of the cylinder block & head are imported and characterized by compact space, smaller weight, lower vibration & noise, higher reliability with an overhaul period of more than 12000 hours;
l The index of the fuel consumption is much better by adopting the P7000 type fuel injection pump and P type injector; consumption of the oil is much lower by adopting the Yuchai’s special sealing technology for the piston rings and oil sealing technology for the valve;
l It is an ideal power which can be used as the main machine for cargo ships, fishery vessels, passenger ships & speedboats and as the ancillary machine for 100--120kW gen-sets.
