Electro Magnetic Door Locks For Home 1200 LBs Holding Force
Electro Magnetic Door Locks For Home 1200 LBs Holding Force
Electro Magnetic Door Locks For Home 1200 LBs Holding Force
Electro Magnetic Door Locks For Home 1200 LBs Holding Force
Specifications
Brand Name :
GSKA
Model Number :
EM-5120
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T
Supply Ability :
2000 pcs per month
Delivery Time :
2 weeks
Packaging Details :
Standard box Packing
Holding Force :
1200 LBS
Material for shell :
Anodized Aluminium
Material for Armature :
Zinc
Weight :
4.5KG
Material for magnetic :
Zinc
Description

Locktronix 12/24VDC Zinc 1200 LBs holding force Electro magnetic door lock

EM-55120 LED 1200Lbs single door electric lock .Suitable for many types of doors including wooden door, glass door , metal door , fireproof door. With lock status signal output ( NO,NC,COM) and LED indiCAT-parts-partsor to show the status of lock.

Dimensions: 265L x 74W x 39H (mm)
Armature Plate: 185L x 63W x 13H (mm)
Holding Force: 500kgs (1200Lbs)
Voltage: 12/24VDC+10%
Current Draw: 12V/420mA, 24V/210mA
Suitable For: Wooden Door, Glass Door, Metal Door, Fireproof Door
Door Status Sensor: (NO/ NC/ COM)
LED IndiCAT-parts-partsion: Green – Door Lock ; Red – Door Unlock
Surface Temp: +20°C
Operating Temp: 10~+55(14-131F)
Suitable Humidity: 0~90% (Non-condensing)
Material For Shell: Anodized Aluminium
Material For Magnetic: Zinc
Material For Armature: Zinc
Weight: 4.5kgs
Optional Bracket: LBK-5120L,LBK-5120Z
