Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control
Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control
Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control
Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control
Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control
Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control
Specifications
Brand Name :
GSKA
Model Number :
DSE8610
CertifiCAT-partsion :
CE SGS ROHS UL
Place of Origin :
Donggaun,china
MOQ :
1set
Price :
negotiate
Payment Terms :
L/C, T/T
Supply Ability :
500 Set / Sets per Month
Delivery Time :
5-7 working days after received deposit
Packaging Details :
Export package
Warranty :
1 months
Function :
Intelligent Automatic Generator Controller
Product Name :
Generator Control Panel
SpecifiCAT-partsion :
29.5*18*6.5cm
Stock :
DSE8610 in stock
Description

Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control

product presentation:

The automation controller of Smartgen series power station integrates digital, intelligent and networked technologies. It is used for automation and monitoring system of single generator set, realizing automatic startup/shutdown, data measurement, alarm protection and "three-remote" functions of generator set. The controller adopts large screen liquid crystal (LCD) display, Chinese, English, Spanish and Russian optional interface operation, simple operation, reliable operation.

The automatic controller of series power station adopts microprocessor technology, realizing the precision measurement of various parameters, setting value adjustment, timing, threshold setting and other functions. All parameters of the controller can be adjusted from the front panel of the controller, or adjusted by using the programming interface of the PC, or adjusted and monitored by using the RS485 interface of the PC. Its compact structure, simple connection, high reliability, can be widely used in various types of generator set automation system.

SpecifiCAT-parts-partsion
DC SUPPLY
CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous
MAXIMUM OPERATING CURRENT
85 mA at 12 V, 96 mA at 24 V
MAXIMUM STANDBY CURRENT
51 mA at 12 V, 47 mA at 24 V
MAXIMUM SLEEP CURRENT
35 mA at 12 V, 32 mA at 24 V
MAINS (UTILITY)
VOLTAGE RANGE
15 V to 415 V AC (Ph to N)
26 V to 719 V AC (Ph to Ph)
FREQUENCY RANGE
3.5 Hz to 75 Hz
OUTPUTS
OUTPUT A (FUEL)
10 A short term, 5 A continuous,at supply voltage
OUTPUT B (START)
10 A short term, 5 A continuous,at supply voltage
OUTPUTS C & D
2 A DC at supply voltage
AUXILIARY OUTPUTS E,F,G,H
2 A DC at supply voltage
GENERATOR
VOLTAGE RANGE
15 V to 415 V AC (Ph to N)
26 V to 719 V AC (Ph to Ph)
FREQUENCY RANGE
3.5 Hz to 75 Hz
MAGNETIC PICK-UP
VOLTAGE RANGE
+/- 0.5 V to 70 V
FREQUENCY RANGE
10,000 Hz (max)

Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control

Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control

Smartgen Series Generator Set Controller Remote Monitoring And Automatic Control

FQA:

1. who are we?
We are based in Dongguan, China, start from 2021,sell to Mid East(45.00%),North America(35.00%),South America(20.00%). There are
total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3. what can you from us?
Generator AVR,Generator Controller,Rectifier Diodes,ATS,Solenoid

4. why should you buy from us not from other supplier?
1.10 YEARS MANUFACTURE,DESIGN AND RESEARCH EXPERIENCE. 2. Owned 3 factories for AVR CONTROLLER AND RECITIFIER 3. OEM FACTORY FOR
FAMOUS GENERATOR COMPANY 4. 8 YEARS PROFESSIONAL SALES TEAM TO PROVIDE BEST SERVICE 5. MOST STRICT QUALITY AND COST CONTROL

5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
