Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Specifications
Place of Origin :
China
Brand Name :
JIWEI
Model Number :
WP13D
Price :
Negotiabce
Certification :
CE
MOQ :
1
Payment Terms :
T/T
Rated Voltage :
400V , 230V
Rated Current :
400A-480A
Speed :
1500RPM, 1800RPM
Frequency :
50/60hz
Starting system :
24V DC Electric Start, 12V DC Electric Start
Type :
Container Type, Open Frame, Mobile Type
Cooling System Type :
Water Cooling System
Warranty :
Other
Rated power :
500 Kw / 625 Kva/600 Kw / 750 Kva
Engine :
WP13D
Product name :
500 Kw / 625 Kva/600 Kw / 750 Kva Weichai diesel generator set
Color :
customizable
Description
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set

Overview

Product characteristics

● Excellent performance: stable and reliable operation, suitable for communication, oil, railways, highways, buildings and other fields, can be used as an uninterruptible power supply, backup and common power supply.

High efficiency and energy saving: The use of efficient fuel injection technology and advanced turbocharging mechanism, high combustion efficiency, low fuel consumption rate, high energy efficiency.

● Environmental protection and low noise: in line with international environmental standards, low emission level, using noise mitigation technology, the noise is controlled in a low range.

● Advanced design: integrated crankshaft box structure and modular design technology, light weight, small volume, high efficiency.

● Easy maintenance: compact structure, easy operation, flexible maintenance, high degree of automation, can adjust the output voltage and frequency according to load changes, and can achieve remote control.

Gen-set specifications
Model JW-WP633
Standby Rating kVA/kWe 687.5/550
Prime Ratng kVA/kWe 625/500
Voltage V 400/230
Frequency Hz 50
Power Factor 0.8(lagging)
No.of Phases 3
Fuel consumptlon@25%50%/75%(Lh) 37.5/66.2/97.1
Fuel consumptlon@100%/110%(Lh) 128.4/143.9
Sound@1m(dB · (A)) Opens103;Silence ≤95
Amblent temp(℃) -10~45
Gen-set regulaton class ISO 8528-5G2
Steady-state voltage deviation S±2.5%
Translent voltage devlation(100%sudden power
decrease/increase)		 S+25%;S-20%
Steady-state frequency band S1.5%
Translent frequency devlatlon from rated frequency
(100%sudden power decrease/increase)		 ≤+12%;S-10%
Typical Enclosed Genset Dimensions
Genset Model Rated
Power
(kW)		 Length
A(mm)		 Width
B(mm)		 Height
C(mm)
Wet
Weight*
(kg)		 Standard
Fuel tank
Capacity
(L)
JW-WP633B73 500 3850 1680 2100 5200 /
JW-WP63F73 500 3850 1680 2100 5600 700
JW-WP633L73 500 5300 2100 2780 7200 650
*:Include coolant and oil.
Land Based Genset-JW-WP725
Gen-set specifications
Model JW-WP725
Standby Rating kVA/kWe 825/660
Prime Rating kVA/kWe 750/600
Voltage V 400/230
Frequency Hz 50
Power Factor 0.8(lagging)
No.of Phases 3
Fuel consumption@25%/50%/75%(Lh)75%(Lh) 45.8/82.0/114.2
Fuel consumption@100%/110%(Lh) 152.6/172.4
Sound@1m(dB · (A)) Open≤106;Silence ≤95
Ambient temp(℃) -10~45
Gen-set regulation class ISO 8528-5 G2
Steady-state voltage deviation ≤±2.5%
Transient voltage deviation(100%sudden power
decrease/increase)		 ≤+25%;≤-20%
Steady-state frequency band ≤1.5%
Transient frequency deviation from rated frequency
(100%sudden power decrease/increase)		 ≤+12%;≤-10%
Typical Enclosed Genset Dimensions
Genset Model Rated
Power
(kW)		 Length
A(mm)		 Width
B(mm)		 Height
C(mm)		 Wet
Weight*
(kg)		 Standard
Fuel tank
Capacity
(L)

JW-WP725B73		 600 3900 1680 2150 5800
/
JW-WP725F73 600 3900 1680 2250 6150 700
JW-WP725L73 600 5500 2180 2780 7400 650
*:Include coolant and oil.

For detailed parameters, please consult me.

We have cooperation with worldwide famous brands. For more specification,please contact us.
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Cost-Effective 500kw 625kva Weichai Engine 600kw 750kva Diesel Generator Set
Our OEM Partners
are from different brands. With our customized solutions consistently delivering satisfaction ,we have won an esteemed reputation.
FAQ
1.Q: What is your MOQ of this item?
A:1 Sets.
2.Q: What is the lead time?
A:7 working days after received the 30%T/T deposit.
3.Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A:Shanghai or others.
5.Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.
6.Q: What is your company's available production capacity?
A:100 Sets per month.
7.Q:What's the warranty time of diesel generators?
A:12 months or 1000 working hours, whichever comes first.

Why choose Jiwei to buy a generator set:

First, environmental protection and fuel saving: The advantages of gasoline generator include: optimized performance, ‌ flexible control, ‌ reduce NOx emission, ‌ high precision control, low vibration, low noise, low maintenance cost; ‌
Second,Delivery Guarantee: 1.fast delivery time: 1-5 days after receiving the deposit, except for special models; 2.Jiwei Company has been established for 20 years, with rich pre-sales and after-sales service capabilities, strong supply capabilities, stable supplier resources and rich logistics resources;
Third, strict quality inspection and testing procedures: 1.each generator set has to go through a comprehensive test program, including 50% load, 75% load, 100% load, 110% load and all control and alarm, safety shutdown function inspection and certification.
Fourth, service guarantee 1.provide free technical support, drawing design; 2.warranty time :2 years or 2000 hours to the first arrival (delivery starts to calculate the time); 3.service response time: within 30 minutes (telephone response); 4.spare parts supply: common repair, maintenance spare parts supply (shipped in China); 5.warranty address: global warranty; Fifth,Customized Services: can be more customized products and LOGO according to your needs;
Sixth,Confidentiality we can sign quality assurance and confidentiality agreements with you, so that our cooperation is more stable;
