Specifications
Place of Origin :
China
Brand Name :
JIWEI
Model Number :
WP4.1
Price :
Negotiable
Certification :
CE
MOQ :
1
Payment Terms :
T/T
Rated Voltage :
400V , 230V, 380V, 480V
Rated Current :
90A-144A
Speed :
1500RPM, 1800RPM
Frequency :
50/60hz
Starting system :
24V DC Electric Start
Type :
Container Type, Open Frame, Mobile Type
Cooling System Type :
Water Cooling System
Warranty :
Other
Rated power :
60KW 75kva
Engine :
WP4.1
Product Name :
Silent 60kw weichai diesel generator
Color :
Customizable
Description
Beautiful Appearance And Low Noise 60KW 75kva Weichai Engine Diesel Generator Set
overview

peculiarity

● Engine quality assurance: Produced by Weichai (Shandong) Co., LTD., it adopts advanced combustion system and fuel injection technology to ensure low fuel consumption and low noise.

High efficiency and energy saving: with excellent energy conversion efficiency, excellent performance under high load working conditions, compared with traditional generator sets can reduce fuel consumption.

● Stability: The use of advanced control system and voltage regulation technology, the output voltage is constant and small fluctuation, for all kinds of electrical equipment stable power supply.

● Convenient operation and maintenance: reasonable design, remote control start and stop system, with good fault self-diagnosis function, easy operation and maintenance.

● Multiple protection mechanism: equipped with overvoltage protection, undervoltage protection, overload protection, short circuit protection and other functions to ensure the safety of equipment and personnel.

Land Based Genset-JW-WP66
Gen-set specifications
Model JW-WP66
Standby Rating kVAkWe 68.5/55
Prime Rating kVAkWe 62.5/50
Voltage V 400/230
Frequency Hz 50
Power Factor 0.8(lagging)
No.of Phases 3
Fuel consumption@25%/50%/75%(Lh) 4.34/7.12/9.46
Fuel consumption@100%/110%(Lh) 13/14.13
Sound@1m(dB · (A)) Open≤105 dB(A);Silence≤85 dB(A)
Ambient temp(℃) -10~45
Gen-set regulation class ISO8528-5 G2
Steady-state voltage deviation ≤±2.5%;≤±5%
Transient voltage deviation
(100%sudden power decrease/increase)		 +25%;-20%
Steady-state frequency band ≤1.5%
Transient frequency deviation from rated frequency
(100%sudden power decrease/increase)		 +12%;-10%
Standard Features
◆ Electronic governor ◆DC24 Electric starter ◆JW-WHC6120NC
◆Closed water-cooled ◆ IP23 ◆H type insulation
◆Air filter ◆Muffler ◆Circuit Breaker
◆Startingbatteries ◆with connective wires ◆ Radiator
◆Oil Drain Valve ◆Forklift Groove ◆Shock Absorber
◆Color Weichai blue(B,F)/beige canopy and black chassis(L)
◆ Packagng packing case(B,F)
Options
OVoltage380V/415V OVoltage 440V/480V ◇Extemal fue tank
(1000L/1500L)
◇Single Voltage 220V/230V OAutomatic Transfer Switch ◇Altermator heater
◇Engine Heater(water) ◇PMG/AREP
Typical Enclosed Genset Dimensions
Genset Model Prime
Rating
(kVA)		 Length
A(mm)		 Width
B(mm)		 Height
C(mm)		 Wet
Weight*
(kg)		 Standard
Fuel tank
Capacity
(L)
JW-WP66B1 50 1930 860 1218 925 /
JW-WP66F1 50 1930 860 1218 1030 105
JW-WP66L1 50 2880 1050 1600 1420 180
:Include coolantand oil
We have cooperation with worldwide famous brands. For more specification,please contact us.
1500RPM 60KW 75kva Generator Silent Box Weichai Engine Low Noise Quiet Portable Generator
1500RPM 60KW 75kva Generator Silent Box Weichai Engine Low Noise Quiet Portable Generator
1500RPM 60KW 75kva Generator Silent Box Weichai Engine Low Noise Quiet Portable Generator
1500RPM 60KW 75kva Generator Silent Box Weichai Engine Low Noise Quiet Portable Generator
1500RPM 60KW 75kva Generator Silent Box Weichai Engine Low Noise Quiet Portable Generator
Our OEM Partners
are from different brands. With our customized solutions consistently delivering satisfaction ,we have won an esteemed reputation.
FAQ
1.Q: What is your MOQ of this item?
A:1 Sets.
Q: What is the lead time?
A:7 working days after received the 30%T/T deposit.
3.Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A:Shanghai or others.
5.Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.
6.Q: What is your company's available production capacity?
A:100 Sets per month.
7.Q:What's the warranty time of diesel generators?
A:12 months or 1000 working hours, whichever comes first.
