High speed Corrugator Belt with High Absorption Permeability 9mm Clipper with Rubber Coated
High speed Corrugator Belt with High Absorption Permeability 9mm Clipper with Rubber Coated
High speed Corrugator Belt with High Absorption Permeability 9mm Clipper with Rubber Coated
High speed Corrugator Belt with High Absorption Permeability 9mm Clipper with Rubber Coated
Specifications
Brand Name :
HUATAO
Model Number :
Huataobelt-016
Place of Origin :
CHINA
MOQ :
10M2
Price :
Price accept negotiation
Payment Terms :
Western Union, T/T,, L/C
Supply Ability :
60000M2/YEAR
Delivery Time :
15-20days
Packaging Details :
wooden box
Material :
100% Synthetic
Thickness :
9±0.3mm
Width range :
1000mm - 3200mm
Heat resistance  :
220℃,the kevlar edge upto 350℃
Weight  :
7.5kg/m2
Length :
80m
Seam :
Clipper Fastener with Rubber Coated/Hot Jaw lacing
Description

High speed Corrugator Belt with High Absorption Permeability 9mm

Production Description:

High speed Corrugator Belt with High Absorption Permeability 9mm This type of belt has very good water absorption ability to ensure the corrugated board fast drying in the production. And could help to save more energy cost.we also supply : needle corrugator belt , woven corrugator belt ,single facer traction belt,corrugating rolls

Corrugator belt - Features

Suitable as top belt with high speed (above 150m/min ) production

Heat and Super tear resistance

Quick absorption and emission of heat

Particularly for frequent changes of board width

Suitable for BHS/Fosber/Agnati/TCY and other brand corrugators

High speed Corrugator Belt with High Absorption Permeability 9mm Clipper with Rubber Coated

Corrugartor Belt Specification

Product Hydrophilic Woven Corrugator Belt
Thickness 9mm
Width range 1000mm - 3200mm
Length 80 meters
Heat-resistance 240℃ (the kevlar edge upto 350℃)
Tensile strength 70Mpa
Coefficient of friction ≥ 0.40µ
Weight per unit (7.5±0.3)kg/㎡
Air-permeability 40mm water Column 2.1m³/㎡ min
Seam Hot JAW lacing/Clipper with rubber coated
Edge 100mm or 200mm inwoven aramid edge reinforcement (kevlar)
Suitable position Top belt

Used on all corrugators high tearing resistance

Long life time running High abrasion resistance

Moisture absorption Heat resistance Low noise

Corrugator Belt Seam

Model1:Fastener Clipper With Rubber Coated

Model2:Hot JAW Lacing

Corrugator Belts Package

Type-I: Waterproof film+Dampblanket+Plasticbag+pallet

Type-II: Waterprooffilm+Dampblanket+Plasticbag+woodpackage+pallet

Note: The wooden box use non-fumigation wood box, it's convenient to customs clearance.Could save customers more time.

High speed Corrugator Belt with High Absorption Permeability 9mm Clipper with Rubber Coated

Why Choose Us ?

Our team of senior engineers can organize the best commodity source for you. By supplying the best Chinese products, Professional design and responsible attitude on service,we devote to creating our unique brand "HUATAO" in global. Since the establishment, " HUATAO " products have been supplied to more than 20 countries and set up the agencies. And our products and service have been recognized and trusted by the end users all the way. We believe, once we have the cooperation, "HUATAO" will be your most reliable partners in your road to success. Because of trust , business will be simple.
