4 Layer Bentonite GCL Geosynthetic Clay Liners with HDPE Geomembrane 50m / Rolls
4 Layer Bentonite GCL Geosynthetic Clay Liners with HDPE Geomembrane 50m / Rolls
4 Layer Bentonite GCL Geosynthetic Clay Liners with HDPE Geomembrane 50m / Rolls
4 Layer Bentonite GCL Geosynthetic Clay Liners with HDPE Geomembrane 50m / Rolls
Specifications
Brand Name :
HT
Model Number :
HUATAO-GCL-001
Certification :
ISO9000
Place of Origin :
CHINA
MOQ :
5000 m2 per order
Price :
Price accept negotiation
Payment Terms :
T/T, L/C, Western Union
Delivery Time :
5-8 work days
Packaging Details :
Paper or iron tube with waterproof film
Material :
geotextile, bentonite
Type :
Geosynthetic Clay Liner
Bentonite mass weight :
5000GSM
WIDTH :
2-6m
name :
Geosynthetic Clay Liner of 3 layer
Description

Geosynthetic Clay Liner of 4 layer with HDPE geomembrane 50m/rolls, weight 4000-6000g/m2

Geosynthetic clay liners (GCLs) with HDPE geomembrane introduction:

Geosynthetic clay liners (GCLs) with HDPE geomembrane Introduction:

Sodium bentonite geosynthetic clay liner Geosynthetic Clay Liner,5000g Bentonite Gcl is a kind of special used for artificial lake water, landfill, underground garage, the roof garden, pool, oil and chemical storage area such as seepage prevention of geosynthetic materials, it is made of high dilatability of sodium base bentonite filling between the special composite geotextile and non-woven fabric, with acupuncture law into bentonite seepage control pad can form many small fiber space, is bentonite particles can not be like a direction, when under the influence of water within the mat forming uniform density of colloidal membrane, prevent the leakage of water.

Geosynthetic clay liners (GCLs) with HDPE geomembrane Technical Parameter:

Inspection Item Testing Procedure Technical Index
Bentonite mass for unit area ASTMD5993 ≥5.5kg/m2
Expansion coefficient ASTMD5890 ≥ 25mL/2g
Low temperature ductility ASTMD5898 No impact at -35°C
Thickness ASTMD5892 ≥6.4mm
Tensile strength ASTMD4632 ≥540N
Peel strength of concrete face ASTMD4632 ≥3.0 KN/ m2
Peel strength ASTMD4632 ≥68N
Indicated flow ASTMD5887 ≤1 × 10-8m3/m2/sec
Hydrostatic pressure resistance ASTMD5888 ≥70
Permeability ASTMD5887 ≤5 × 10-12cm/sec
Extension rate ASTMD5896 ≥20
Puncture strength ASTMD5894 ≥635N


Geosynthetic clay liners (GCLs) with HDPE geomembrane Property:

1. Environment friendly
2. Long-lasting waterproof performance
3. Easy application

Geosynthetic clay liners (GCLs) with HDPE geomembrane Advantage
1. Excellent raw material
We choose the best natural sodium bentonite to guarantee our good quality.
2. Competitive price
Our advanced production line, quality control and analysis system and convenient transportation to shanghai port help us the reduce cost, so that we can provide you competitive price.
3. First-class service and product
“Quality first, customer is god. ”is our doctrine. We will serve for our customer with all our effort.

Geosynthetic clay liners (GCLs) with HDPE geomembrane Application:

· Landfills · Mud Pits
· Lagoons · Canals
· Bund Lining · Tank Lining
· Fish Farm Lining · Roof Lining
· Waste Water Pits · Ponds and Reservoirs
· Dams · Floating Covers
· Vertical Cutoff Walls · Hydraulic Structure
· Basement Lining · Drip Irrigation Ponds


4 Layer Bentonite GCL Geosynthetic Clay Liners with HDPE Geomembrane 50m / Rolls
