Polyester Filament Nonwoven Geotextile Filter Fabric 300g
Polyester Filament Nonwoven Geotextile Filter Fabric 300g
Polyester Filament Nonwoven Geotextile Filter Fabric 300g
Polyester Filament Nonwoven Geotextile Filter Fabric 300g
Specifications
Brand Name :
Wanshengli
Model Number :
Customized
Certification :
CE, ISO, SGS, GB, ASTM
Place of Origin :
Luan, China
MOQ :
1100sqm
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000 sqm per day
Delivery Time :
5~8 working days
Packaging Details :
Woven Plastic bags or as your request
Geotextile Material :
Polyester
Product Color :
White or black
Product Length :
50-200m/roll or as per your request
Width :
6m or as your request
Gram Weight :
100g/㎡~1500g/㎡
Sample :
Free provided
MOQ :
1100 sqm/2200sqm
Break elongation :
25~100%
Description
300g Filament Geosynthetic Fabric Geotextile With High Physical Mechanical Features
Geosynthetic Fabric Short Non Woven Geotextile

Wanshengli brand filament geotextile is interweaved into net by high technology, advanced equipment and special steps with different kinds of fibers by needling punch and other procedures.

Because of the difference yarn, it has 2 types:

1. non woven short fiber geosynthetic fabric geotextile

2. non woven filament geosynthetic fabric geotextile

Filament geosynthetic fiber geotextile has resistance of high temperature up to 230℃ to guanrantee maintain structure stability, high flat drainage, high elongation under certain stress, high creep resistance and vertical permeability, so can be applied in uneven and irregular bases. Many geotechnical engineering projects can use short non-woven geotextile filament fiber as materials.

Quick Detail:

material: PP polypropylene, PET polyester

function: protection, isolation, reinforcement, drainage
thickness: 2.4mm
application: landfills, chemical plant, sewage plant

Geosynthetic Fabric Features

  • Good flexibility
  • Corrosion resistance
  • Acid and alkali resisitance
  • Oxidation resistance
  • Good water permeability
  • Filtration and isolation performance
Polyester Filament Nonwoven Geotextile Filter Fabric 300g
Product Parameter
No.

Item

Index

Specification

 100 150 200 250 300 350 400 450 500 600 800 Remarks
1 Unit area mass deviation,% -8 -8 -8 -8 -7 -7 -7 -7 -6 -6 -6
2 thickness, mm ≥ 0.9 1.3 1.7 2.1 2.4 2.7 3 3.3 3.6 4.1 5
3 Width deviation, % -0.5
4 Breaking strength, KN/M ≥ 0.08 0.12 0.16 0.2 0.24 0.28 0.33 0.38 0.42 0.46 0.6 Vertical and horizontal
5 Elongation at break, % 25-100
6 CBR bursting strength,KN ≥ 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.2 4
7 Equivalent aperture,O99(O35),mm 0.07-0.2
8 Vertical permeability coefficient,cm/s KX(10 -1 -10 -3 ) K=1.0-9.9
9 Tear strength 3,KN ≥ 0.08 0.12 0.16 0.2 0.24 0.28 0.33 0.38 0.42 0.4 0.6 Vertical and horizontal

Applications

  • As the isolation layer and for inverted layer dam, slope protection, road, railway, airfield runway.
  • Reinforcement and drainage for soil slope,retaining wall.
  • Reinforcement and drainage for Asphalt pavement, cement concrete pavement and subgrade enhancement. Both rigid and flexible road pavement applicable.
  • Soft foundation treatment/ soft soil improvement of port project; the reinforcement and drainage for beach dike, seaport wharf and seawall/bulwark.

Polyester Filament Nonwoven Geotextile Filter Fabric 300g

Polyester Filament Nonwoven Geotextile Filter Fabric 300g

Geosynthetic Fabric Geotextile Package

packed as rolls with tight belt and woven bags. I t can gurantee onvenient unloading and protecting product.

Polyester Filament Nonwoven Geotextile Filter Fabric 300g

Polyester Filament Nonwoven Geotextile Filter Fabric 300g

Polyester Filament Nonwoven Geotextile Filter Fabric 300g

Polyester Filament Nonwoven Geotextile Filter Fabric 300gPolyester Filament Nonwoven Geotextile Filter Fabric 300gPolyester Filament Nonwoven Geotextile Filter Fabric 300gPolyester Filament Nonwoven Geotextile Filter Fabric 300gPolyester Filament Nonwoven Geotextile Filter Fabric 300gPolyester Filament Nonwoven Geotextile Filter Fabric 300g
