ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
Specifications
Type :
Geocells
Warranty :
More than 5 years
After-sale Service :
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other
Project Solution Capability :
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, NONE
Application :
garbage landfill water conservancy
Design Style :
Industrial
Place of Origin :
Shandong, China
Brand Name :
TENGLU
Model Number :
TLGCL
Product name :
Geosynthetic clay liner
Raw Material :
sodium-based bentonite special geotextile
Keyword :
GCL Geosynthetic clay liner For Water Conservancy
Color :
Black Green White
width :
4-6m
weight :
3500g-6500g
Length :
30-50m
Certifications :
CE ISO14001 ISO9001
MOQ :
500 Square Meter
Function :
waterproof and seepage control engineering
Packaging Details :
*Plastic bag, PP woven bags or follow customers' demand.
*Highly keep away from fire and high temperatures.
*Logo marked is accepted on the package.
Port :
Qingdao Port, Tianjin Port, Shanghai Port of China
Supply Ability :
10000 Square Meter/Square Meters per Day
MOQ :
500 square meters
Price :
$1.51/square meters 500-4999 square meters
Description
Products Description
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
Geosynthetic Clay liner
Geosynthetic clay liner is composed of high dilatability of sodium base bentonite filling between the special composite geotextile
and nonwoven fabric, made by the method of acupuncture or suture composite impervious material. Use acupuncture into geosynthetic
clay liner can form many small fiber space, make the bentonite particles can't flow in one direction, when under the influence of
water within the mat forming uniform density of colloidal waterproof layer, prevent the leakage of water. For different
projects,it can combine HDPE liner for better waterproof
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
Specification
Item
Technical Index
material
≥4000,Not Less Than Specified Value
≥4000,Not Less Than Specified Value
≥4000,Not Less Than Specified Value
Mass per Unit
GCL-NP
GCL-OF
GCL-AH
Swelling index of Bentonite(ml/2g)
≥24
≥24
≥24
Adsorbed Methylene Blue(g/100g)
≥30
≥30
≥30
Tensile Strength(N/100mm）
≥600
≥700
≥600
Max.Elongation Under Load（%）
≥10
≥10
≥8
Peel Strength(N/100MM)
Non-woven Cloth and Woven Cloth
≥40
≥40
-
thickness
PE Film and Non-woven Fabric
-
≥30
-
Permeability Coefficient(m/s)
≤5.0*10-11
≤5.0*10-12
≤1.0*10-12
Resistance to Hydrostatic Pressure
0.4MPa,1h,No Leakage
0.6MPa,1h,No Leakage
0.6MPa,1h,No Leakage
Filtration Loss(ml)
≤18
≤18
≤18
Durability of Bentonite(ml/2g)
≥20
≥20
≥20
NP is a normal index,our expansion coefficient is 28,the peeling strength can reach 65N,and the tensile strength can reach 1000N.Of them belong to the waterproof blanket coverd with film ,AH.
Related products
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy

Geotextile Geogrid Geomembrane Cement blanket

ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
Grass Grid Plastic Drainage Board 3D Geomat
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy

Geosynthetic Clay Liner Production line Geogrid Prodution line


ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
Geotextile Production Line Geocell Prodution Line Geomembrane Prodution Line
Company Profile
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
Tai'an Tenglu Engineering Materials Co., Ltd. is located at the foot of Mount Tai---Taian, Shandong. The company has always adhered to the enterprise spirit of "honesty, credit first", specializing in the production of geomembrane, geotextile, geogrids, geocells, geonet, cement blanket, geosynthetic clay liner, 3D composite drainage geonet, plastic drainage board, permeable pipe and other series of geosynthetic materials. The products are widely used in the foundation reinforcement of highways, railways, airports, municipal engineering, anti-seepage of construction projects, landscaping, landfills, sewage treatment, solid waste disposal, waterproof engineering, etc.

"Gui Nuo Lian jin" is our company's principle. We follow the Confucian style and corporate morality in our operations, and have won a good social reputation. In production, we insist on taking science and technology as the guide and management as the guarantee, so that the product quality is Topping the list in the same industry. The company has successfully passed the ISO9001 quality management system certification, and related products have been identified by China Railway, China Construction, China Communications, China Metallurgical, China Hydropower and other departments, and have obtained long-term cooperative relations with relevant units. Some products have been tested by the Swiss General Notary Public (SGS) and obtained the test report.

Warmly welcome friends from all over the world to visit and guide, and we are willing to cooperate sincerely with you to create brilliant achievements.
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
Packing & Delivery
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy

Packing Instructions

Packed in roll and put in woven bags or follow the customer requirements .
Customer's logo on package available.

Company team
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
Certifications
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
ISO14001 Certified Sodium-Based Bentonite Geosynthetic Clay Liner for Water Conservancy
FAQ
Q1: Are you trading company or manufacturer?
A: We are officially licensed MANUFACTURER specializing in the research, production and supplying of geosynthetics with 20 years experience.

Q2: How about the quality of your products?
A: We have professional and advanced brand machine production line and quality control center. Each batch of products will be sampled before package and there also has final inspection before shipment.

Q3: Can you provide sample?
A: Yes, we can offer free samples of some items for quality evaluation.

Q4: Can you accept small order?
A: Yes.Our minimum order quantity is 1000㎡.

Q5: Do you accept customized design order?
A: Yes.We welcome customized design orders.

Q6: What is your lead time?
A: General within 7-15 days, large order can be negotiated.

Q7: What’s your delivery term?
A: We can accept EXW, FOB, CIF, etc (follow customers' request)

Q8. What is the payment way?
A: Online Bank Payment,T/T,L/C,D/P D/A,PayPal,Western Union.
