Specifications
Place of Origin :
China
Brand Name :
HongHuan
Certification :
ISO9001
Model Number :
SNG150
MOQ :
10,000/m^2
Packaging Details :
PVC or PP Fabric Rolls
Delivery Time :
30 days
Payment Terms :
T/T, L/C
Material :
Polyester/Polypropylene
Color :
white/grey/black
Type :
Non-woven Geotextile
Unite mass :
150gsm
Packing :
film or as per your request
Width :
1m-6m
Description

PET Needle Punched Non Woven Geotextile Filter Fabric For Slope 150G


Description:
Short Fiber Needle-punched non-woven Geotextiles SNG® are made from PET/PP fibres that are tangled together by a needle-punching process. The fibres that achieve their strength by interlocking. Needle-punched non-woven Geotextiles have excellent water flow rates and are used for filtration of soil fines for drainage applications including trench drains, as a wrapping for perforated pipe, for erosion protection, and combined with three-dimensional structures to create prefabricated drains.

SNG150® Specification Date Sheet:

SNG150® Technical Specification

Property

Test Method

Metric Value

English Value

Mass Per Unit Area

ASTM D 5261

150 g/m²

4.4 oz/yd²
Thickness

ASTM D 5199

 1.3 mm 121 US Sieve

Tensile strength

ASTM D 4595

4.5 KN/m

1011 lbs

Elongation

ASTM D 4595

50%

50%

Apparent Opening Size

ASTM D 4751

0.10 mm

9 US Sieve

Permittivity

ASTM D 4491

NA

NA

Water Flow Rate

ASTM D 4491

2500 L/min/m2

62 g/min/sf

Trapezoidal Tear Strength

ASTM D 4533

0.12 KN

27 lbs

CBR Puncture Strength

ASTM D 6241

0.60 KN

135 lbs

UV Resistance
(% retained after 500 hours)

ASTM D 4355

70%

70%

ROLL DIMENSIONS

Roll Width

4 M

13.2 ft

Roll Length

100 M

382.9 ft

Roll Weight

60 KGS

132 lbs

NOTES:
·

Features:The values given are Minimum Average Values except elongation and UV resistance. Elongation Maximum Value and UV Temperature Range: -60°C ~ +170°C
Permeability: Excellent uniformity with high permeability and low pore size for soil filtration.
Storage and transportation is convenient: Because of light weight, packing can be according to certain requirements, so the transport, storage, construction is very convenient.

Applications:

  • Water conservancy priject and hydropower project
  • Road paving, railway
  • Airport and port
  • River bank protection and tunnel
  • Environmental applications
