Woven Geotube Dewatering Bags For Breakwater Embankment Cofferdam Jetty Riverbank
Woven Geotube Dewatering Bags For Breakwater Embankment Cofferdam Jetty Riverbank
Woven Geotube Dewatering Bags For Breakwater Embankment Cofferdam Jetty Riverbank
Woven Geotube Dewatering Bags For Breakwater Embankment Cofferdam Jetty Riverbank
Specifications
Brand Name :
zhongloo
Model Number :
Geotube
Certification :
ISO,SGS
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
600000sqm Per Days
Delivery Time :
5-8 work days
Packaging Details :
PP Woven Fabric
Model NO. :
Geotube
Material :
PP
Kind :
Woven
Length :
Cutomized
Width :
Cutomized
Type :
Geotube, Woven Knitted
Mass Per Unit :
150GSM-800GSM
Transport Package :
PP Woven Fabric
Specification :
as customized
Description

Sludge Dewatering Geotextile Tube Sand Bag Geo Container Geotube for Breakwater Embankment Cofferdam Jetty Riverbank

Geotubes have different levels of strength and permeability, high UV resistance and durability such as sea water and microbial erosion.

It can be applied to many water conservancy and ocean engineering, such as: bank protection, breakwater, wave breakwater, river surge regulation, tubular containment structure, etc.

At the same time, it is used in the dehydration treatment of industrial waste, sludge treatment, coal mine and agricultural waste.

Woven Geotube Dewatering Bags For Breakwater Embankment Cofferdam Jetty Riverbank

Iterm Unit Standard Index
HT500 HT750 HT1000
Tensile Strength Radial Direction KN/M ISO 10319-2015 85 130 220
Zonal Direction KN/M ISO 10319-2015 115 120 200
Elongation at Break Radial Direction % ISO 10319-2015 13 12 13
Zonal Direction % ISO 10319-2015 8 8 8
Joint Tensile Strength KN/M ISO 10319-2015 90 100 170
CBR KN GB/T14800-2010 9 15 20
Dynamic Perforation MM GB/T17630-1998 8 10 8
Effective Aperture(O90) MM GB/T14799-2005 0.45 0.4/0.28 0.45
Permeability(Q50) L/m2/s GB/T15789-2005 35 14 18
UV Resistance % ASTM D4355-2014 90 85 85

Advantages of Geotube

1. Superior Durability


2. High Permeability


3. UV Resistance


4. High Tensile Strength

Woven Geotube Dewatering Bags For Breakwater Embankment Cofferdam Jetty Riverbank

Product Application

Sludge Treatment

The volume of sludge can be reduced by more than 90%, and it contains a higher proportion of solid content, making it easier to remove and process.

Revetment, Breakwater Core

The embankment core filling geotechnical pipe bag breakwater is a breakwater made of new materials. It forms a kind of breakwater by filling the geotechnical pipe bag with sea sand. Not only saves the construction cost of the breakwater, but also makes better use of environmental resources, and can well meet the construction and functional requirements of the breakwater.

Woven Geotube Dewatering Bags For Breakwater Embankment Cofferdam Jetty Riverbank
