MachineU > China Products > Construction & Real Estate > Earthwork Products > Geogrids
Earthwork Products Biaxial Stretch Plastic Geogrid For Reinforcement
Earthwork Products Biaxial Stretch Plastic Geogrid For Reinforcement
Earthwork Products Biaxial Stretch Plastic Geogrid For Reinforcement
Earthwork Products Biaxial Stretch Plastic Geogrid For Reinforcement
Specifications
Brand Name :
zhongloo
Model Number :
Geogrid
Certification :
CE/ISO9001
MOQ :
1000 square meter/square meters
Price :
USD 0.58-0.74 per square meter
Payment Terms :
D/A, L/C, T/T
Supply Ability :
60000 square meters per day
Delivery Time :
8-12 days
Packaging Details :
Rolling by cardboard core and packed by white woven geotextile with neat state.
Type :
Biaxial Geogrid
Warranty :
8 years
Product Color :
White Black
Raw Material :
PP
Length :
50m
Design Style :
Modern
Description

Earthwork Products Biaxial Stretch Plastic Geogrid For Reinforcement

Product Description

Geogrid is a geosynthetic material made of polymer, used to reinforce the soil behind the retaining wall. The geogrid is installed in the horizontal layer between the wall layers and extends into the soil behind the wall to stabilize the soil, thereby increasing the quality and stability of the wall system. The geogrid reinforced filling structure uses PP geogrid, which is made by extrusion and unidirectional stretching of high-density polyethylene. The high demand for geogrid and its application in construction is due to its good tensile strength and higher performance.

Biaxial Plastic Geogrid Technical Parameter (GB standard)

Item

Specification

TGSG1515

TGSG2020

TGSG2525

TGSG3030

TGSG3535

TGSG4040

TGSG4545

TGSG5050

Vertical and horizontal tensile strength≥(KN/M)

15

20

25

30

35

40

45

50

Tensile strength at 2% elongation≥(KN/M)

5

7

9

10.5

12

14

16

17.5

Tensile strength at 5% elongation≥(KN/M)

7

14

17

21

24

28

32

35

Tensile strength at 5% elongation≥(KN/M)

15

Features

1.With high tensile strength in longitudinal and transverse directions

2.The special structure provides a chain system to get more efficient bearing and spreading reinforce for the soft soil.

3.Adds strength and longevity to wall

4.Aids in prevention of early development of wall failure

5.Provides excellent stress transfer

Product tags

extended plastic geogrid

,

biaxial polypropylene geogrid

,

high tensile strength polyester geogrid
