Specifications
Brand Name :
Zhongloo
Model Number :
ZL-TGM
Certification :
ISO,SGS,TUV,BV
Place of Origin :
China
MOQ :
1000sqm
Price :
USD 0.68-2.99 Per Square Meter
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
2, 000, 000 Square Meter Per Month
Delivery Time :
10-20days
Packaging Details :
Custom Package
Material :
HDPE LDPE LLDPE EPDM EVA
Color :
black green white blue
Thickness :
0.1mm-3.0mm
Description
Geomembrane Pond Liner Description
0.5mm 1mm 1.5mm Plastic Waterproof Aquaculture Geomembrane Hdpe Liner Fish Farm Wholesale Pond Liners HDPE Price
Geomembrane Pond Liner is the kind of black smooth geomembrane HDPE liner which is the ideal geotechnical material for water containment in aquaculture project. Geomembrana HDPE 2 mm is made by high density polyethylene with carbon black or other different colors with adding different color master batch, such as green, blue, transparent, etc. Geomembrana HDPE 2 mm features anti-seepage, excellent resistance to UV radiation and is suitable for exposed conditions which is widely used for solid waste containment, aquaculture mining and water containment applications.
Details Images
Products Advantage
1) Excellent environmental stress cracking resistance property.
2) Low temperature resistance, corrosion resistance, aging resistance.
3) For service temperature range: -60'℃ -+60°C.
4) Service valid term: 60 years at least.
5) Anti-crack, dimensional stability, anti-aging, smooth appearance, high friction coefficient.
Technical Index
HDPE Geomembrane Pond Liner Technical Parameter
Spec
Properties
Test method
ASTM
GMS0.5
GMS0.75
GMS1.0
GMS1.25
GMS1.5
GMS2.0
GMS2.5
Thickness
D5199
0.5mm
0.75mm
1.00mm
1.25mm
1.50mm
2.00mm
2.50mm
Density (≥ g/cc)
D1505
0.940
0.940
0.940
0.940
0.940
0.940
0.940
Tensile Properties
(Each direction) (≥)
• yield strength
• break strength
• yield elongation
• break elongation
D 6693
Type IV


8 kN/m
14kN/m
12%
700%


11 kN/m
20kN/m
12%
700%


15 kN/m
27 kN/m
12%
700%


18 kN/m
33 kN/m
12%
700%


22 kN/m
40 kN/m
12%
700%


29 kN/m
53 kN/m
12%
700%


37kN/m
67kN/m
12%
700%
Tear Resistance (≥)
D 1004
64 N
93 N
125 N
156 N
187 N
249 N
311 N
Puncture Resistance (≥)
D 4833
160 N
240 N
320 N
400 N
480 N
640 N
800 N
Stress Crack Resistance (≥)
D 5397
500 hr.
500 hr.
500 hr.
500 hr.
500 hr.
500 hr.
500 hr.
Carbon Black Content
D 1603
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
Carbon Black Dispersion
D 5596
Note(1)
Note(1)
Note(1)
Note(1)
Note(1)
Note(1)
Note(1)
Oxidative Induction Time (OIT) (≥)
(a)Standard OIT
- or -
(b)High Pressure OIT


D 3895

D 5885


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.
Geomembrane Application
1) Municipal environmental projects, water conservancy projects.
2) Landfill cap, mining heap leach pads.
3) Pond liner, canal linings, tank linings, raw water treatment reservoirs, retention ponds.
4) Waste water treatment lagoon, secondary containment.
