PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
Specifications
Brand Name :
CISCO
Model Number :
PWR-C1-350WAC
Place of Origin :
CN/USA/MALAYSIA
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
T/T, WU, MoneyGram
Supply Ability :
80pcs/week
Delivery Time :
1-3Days
Packaging Details :
Double packing for protecting the original box
Weight :
1.6 kg
Output ratings :
-56V at 6.25A
Input current :
4-2A
Total output BTU :
1207BTU/hr, 350W
Power cord rating :
10A
Product Name :
Cisco Power Supply
Description

PWR-C1-350WAC Cisco Power Supply for Cisco 3850 Series Switches

Cisco 3850 Series Power Supply PWR-C1-350WAC 350W AC Config 1 Power Supply

Brand New Sealed

PWR-C1-350WAC Overview

Cisco 3850 Series Power Supply - PWR-C1-350WAC 350W AC Config 1 Power Supply for 3850 Series.

Quick Specs

Figure 1 shows the appearance of PWR-C1-350WAC.

PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch

Table 1 shows the Quick Specs.

Product Code

PWR-C1-350WAC

Power supply rated maximum

350W

Total output BTU (Note: 1000 BTU/hr = 293W)

1207BTU/hr, 350W

Input-voltage range and frequency

100-240VAC,

50-60 Hz

Input current

4-2A

Output ratings

-56V at 6.25A

Output holdup time

16.7 ms minimum at 100VAC

Power-supply input receptacles

IEC 320-C16 (IEC60320-C16)

Power cord rating

10A

Physical specifications

(H x W x D): 1.58 X 3.25 X 12.20 in

Weight: 2.6 lb
(1.2 kg)

The Modules, Cards, Licenses

Table 2 shows the recommended elements for the PWR-C1-350WAC.

Category

Model

Description

Power Cable

CAB-TA-NA

North America AC Type A Power Cable

CAB-TA-JP

Japan AC Type A Power Cable

CAB-C15-CBN

Cabinet Jumper Power Cord, 250 VAC 13A, C14-C15 Connectors

Compare to Similar Items

Table 3 shows the comparison of PWR-C1-350WAC, PWR-C1-440WDC, PWR-C1-1100WAC and PWR-C1-715WAC=.

Product Code

PWR-C1-350WAC

PWR-C1-440WDC

PWR-C1-715WAC=

PWR-C1-1100WAC

Power supply rated maximum

350W

440W

715W

1100W

Total output BTU (Note: 1000 BTU/hr = 293W)

1207BTU/hr, 350W

1517BTU/hr, 440W

2465 BTU/hr, 715W

3793 BTU/hr, 1100W

Input-voltage range and frequency

100-240VAC,

50-60 Hz

-36VDC to -72VDC

100-240VAC,

50-60 Hz

115-240VAC,

50-60 Hz

Input current

4-2A

<8A at -72VDC

<16A at -36VDC

10-5A

12-6A

Output ratings

-56V at 6.25A

-56V at 7.86A

-56V at 12.8A

-56V at 19.64A

Output holdup time

16.7 ms minimum at 100VAC

> 2ms at -48VDC

16.7 ms minimum at 100VAC

10 ms minimum at 102.5VAC

Power-supply input receptacles

IEC 320-C16 (IEC60320-C16)

Terminal strip

IEC 320-C16

(IEC60320-C16)

IEC 320-C16

(IEC60320-C16)

Power cord rating

10A

20A at 100VDC

13A

13A

PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch

PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch

PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch

PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch

PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch

PWR-C1-350WAC Cisco Power Supply 4-2A 100-240VAC 50-60 Hz 1.58 X 3.25 X 12.20 Inch
