Clean Serial Cisco Catalyst 3850 Switch AC Power Supply 715W PWR-C1-715WAC
Clean Serial Cisco Catalyst 3850 Switch AC Power Supply 715W PWR-C1-715WAC
Clean Serial Cisco Catalyst 3850 Switch AC Power Supply 715W PWR-C1-715WAC
Clean Serial Cisco Catalyst 3850 Switch AC Power Supply 715W PWR-C1-715WAC
Specifications
Brand Name :
CISCO
Model Number :
PWR-C1-715WAC
Certification :
FCC
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500
Delivery Time :
3-5 days
Packaging Details :
CISCO Original Package + Double Carton box to Protect
Warranty :
One Year
Product name :
PWR-C1-715WAC
Weight :
3kg
Condition :
NIB
Products status :
Stock
Manufacturer :
Cisco systems
Shipping :
TNT,ARAMEX,DHL,Air Cargo,FedEx
POE Function :
No
Description

Product Description:

Cisco 3850 Series Power Supply - PWR-C1-715WAC 715W AC Config 1 Power Supply for 3850 Series.

PWR-C1-715WAC= Specification
Power supply rated maximum 715W
Total output BTU (Note: 1000 BTU/hr = 293W) 2465 BTU/hr, 715W
Input-voltage range and frequency

100-240VAC,

50-60 Hz
Input current 10-5A
Output ratings -56V at 12.8A
Output holdup time 16.7 ms minimum at 100VAC
Power-supply input receptacles

IEC 320-C16

(IEC60320-C16)
Power cord rating 13A
Physical specifications

(H x W x D): 1.58 X 3.25 X 12.20 in

Weight: 2.8 lb
(1.3 kg)
Operating temperature 23 to 113°F (-5 to 45°C)
Storage temperature -40 to 158°F (-40 to 70°C)
Relative humidity operating and nonoperating noncondensing 5 to 90% noncondensing
Altitude 10,000 ft. (3000 meters), up to 45°C
MTBF Calculated MTBF must be greater than 300,000 using Telcordia SR-332, Method 1, Case 3. Demonstrated MTBF is 500,000 hr (with 90% confidence level).
EMI and EMC compliance

FCC Part 15 (CFR 47) Class A

ICES-003 Class A

EN 55022 Class A

CISPR 22 Class A

AS/NZS 3548 Class A

BSMI Class A (AC input models only)

VCCI Class A

EN 55024, EN300386, EN 50082-1, EN 61000-3-2, EN 61000-3-3

EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN 61000-6-1
Safety compliance UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
LED indicators

“AC OK”: Input power to the power supply is OK

“PS OK”: Output power from the power supply is OK

Clean Serial Cisco Catalyst 3850 Switch AC Power Supply 715W PWR-C1-715WAC

Related Products:

Apart from PWR-C1-715WAC, you might be interested in below CISCO items too

Clean Serial Cisco Catalyst 3850 Switch AC Power Supply 715W PWR-C1-715WAC

Packing & Shipping:

CISCO Original Package + Double Carton box to Protect

Clean Serial Cisco Catalyst 3850 Switch AC Power Supply 715W PWR-C1-715WAC

Why Choose US?

GPL discount for PWR-C1-715WAC can be 75% above

Clean Serial Cisco Catalyst 3850 Switch AC Power Supply 715W PWR-C1-715WAC

FAQ:

(1) Is this PWR-C1-715WAC NIB?

Yes, it is NIB and with clean serial.

(2) How long is your warranty time?

We have 1 year warranty for our new items, and 90 days warranty for the used.

(3) If have quality issue with your PWR-C1-715WAC, how can you solve it?

If within our warranty, we can refund or replace for you.

If out of warranty, we can repair for you.

(4) How do you ship the CISCO switch PWR-C1-715WAC to me?

We cooperate with DHL, TNT, Fedex, UPS directly, not through forwarder, so most time we can ship them faster. It always takes 1-2 days to Asia, and 2-3 days to EU & Middle East.
