Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
Specifications
Brand Name :
CISCO
Model Number :
WS-C3850-48T-E
Certification :
FCC
Place of Origin :
USA
MOQ :
1unit
Price :
$2535/unit
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
50/unit/day
Delivery Time :
3 days
Packaging Details :
57*56*25cm
Communicatio :
Full-Duplex&Half-Duplex
Stacking bandwidth :
480 Gbps
Products Status :
In Stock
Enclosure Type :
1 RU
Function :
LACP,POE,QoS,SNMP,Stackable
layer :
3
Uplink module :
C3850-NM-4-1G
MTBF hours :
303,660
Description

Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E

Product Information of WS-C3850-48T-E

Description: Cisco Catalyst 3850 48 Port Data IP Services

  • 24 and 48 10/100/1000Mbps data PoE+ and Cisco UPOE models with energy-efficient Ethernet (EEE)
  • 24 and 48 100Mbps/1/2.5/5/10 Gbps Cisco UPOE models with energy-efficient Ethernet (EEE)
  • 48-port 1/10 Gigabit Ethernet SFP+ model with 4 fixed 40 Gigabit Ethernet QSFP+ uplinks

Product Code WS-C3850-48T-E
Enclosure Type 1 RU
Feature Set IP Services
Network SFP uplink module selection

C3850-NM-4-10G

C3850-NM-2-10G

C3850-NM-4-1G
Ports 48 x 10/100/1000 Ethernet ports
Available POE Power 715W
Maximum stacking number 9
Stack bandwidth 480 Gpbs
Switching Capacity 92 Gpbs
Forwarding Performance 68.4Mpps
RAM 4 GB
Flash Memory 2 GB
Dimensions 4.45 cm x 44.5 cm x 44.5 cm
Package Weight

17.49 Kg

Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU EnclosureTable 1 lists the power specifications for the Cisco Catalyst 3850 Series based on the kind of power supply used.

Description

Specification
PWR-C1-1100WAC PWR-C1-715WAC PWR-C1-350WAC PWR-C1-440WDC
Power supply rated maximum 1100W 715W 350W 440W
Total output BTU (Note: 1000 BTU/hr = 293W) 3793 BTU/hr, 1100W 2465 BTU/hr, 715W 1207BTU/hr, 350W 1517BTU/hr, 440W
Input-voltage range and frequency

115-240VAC,

50-60 Hz

100-240VAC,

50-60 Hz

100-240VAC,

50-60 Hz

 -36VDC to -72VDC
Input current 12-6A 10-5A 4-2A

<8A at -72VDC

<16A at -36VDC
Output ratings -56V at 19.64A -56V at 12.8A -56V at 6.25A -56V at 7.86A
Output holdup time 10 ms minimum at 102.5VAC 16.7 ms minimum at 100VAC 16.7 ms minimum at 100VAC > 2ms at -48VDC
Power-supply input receptacles

IEC 320-C16

(IEC60320-C16)

IEC 320-C16

(IEC60320-C16)

 IEC 320-C16 (IEC60320-C16) Terminal strip
Power cord rating 13A 13A 10A 20A at 100VDC
Physical specifications

(H x W x D): 1.58 X 3.25 X 13.7 in

Weight: 3 lb
(1.4 kg)

(H x W x D): 1.58 X 3.25 X 12.20 in

Weight: 2.8 lb
(1.3 kg)

(H x W x D): 1.58 X 3.25 X 12.20 in

Weight: 2.6 lb
(1.2 kg)

(H x W x D): 1.58 X 3.25 X 12.20 in

Weight: 2.6 lb
(1.2 kg)
Operating temperature 23 to 113°F (-5 to 45°C)
Storage temperature -40 to 158°F (-40 to 70°C)
Relative humidity operating and nonoperating noncondensing 5 to 90% noncondensing
Altitude 10,000 ft. (3000 meters), up to 45°C
MTBF Calculated MTBF must be greater than 300,000 using Telcordia SR-332, Method 1, Case 3. Demonstrated MTBF is 500,000 hr (with 90% confidence level).
EMI and EMC compliance

FCC Part 15 (CFR 47) Class A

ICES-003 Class A

EN 55022 Class A

CISPR 22 Class A

AS/NZS 3548 Class A

BSMI Class A (AC input models only)

VCCI Class A

EN 55024, EN300386, EN 50082-1, EN 61000-3-2, EN 61000-3-3

EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN 61000-6-1
Safety compliance UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
LED indicators

“AC OK”: Input power to the power supply is OK

“PS OK”: Output power from the power supply is OK

Package & Delivery

Selling Units Single item
Package Type CISCO F/S NIB original sealed box inside , and another blank carton box to protect it from broken
Shipment Ship Via UPS, DHL, EMS, FEDEX, TNT,EMS, POSTAL etc or other options by clients
Lead Time Fast transportation time within 48 hours after payment confirm
Quantity (Piece) <30 31 - 100 >100
Est. Time (day) 2 3 To be negotiated

Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure

Why Choose US

Warranty 1 Year warranty from professional cisco agents
Service 24 Hours online service
Quality 100% Original Cisco Sealing Products from Cisco Factory.
Price Competitive Price with a big Discount from china mainland
Advantages Cisco China Agents
Providing constructive suggestions for solutions and installations.

Cisco Small Business Gigabit LAN Switch Layer 3 WS-C3850-48T-E 1 RU Enclosure
