Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Z275 RAL 4089 White 2400mm Prepainted Galvanized Steel Sheet In Coils
Specifications
Brand Name :
RAYMOND
Certification :
ISO14000
Place of Origin :
China
MOQ :
50mt
Price :
USD500-800/MT
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/A, D/P
Supply Ability :
10000MT/ month
Delivery Time :
45days
Packaging Details :
standard export packing
Commodity :
Pre-painted steel coil
Zinc Coating :
60g/㎡
Top Surface :
15 Micron Polyester + 5 Micron Primer
Back Surface :
7 Micron + 5 Micron Primer.
Thickness :
0.48mm
Width :
1000mm
Color :
RAL 7065
Application :
Roofing,Structure,Flange Plate,Ship Plate,Container Plate
Description

colour coated steel coils color coated coil colour coated coil prepainted steel coil


PPGI (PPGL) Features:

Product Name
New Updated Colors Roofing Sheets Material PrePainted Galvanized PPGI Steel Coils From China
Standard &grade
JIS G3312 SGCC;EN10346 DX51D,S550GD;ASTM A755 CS-B,Grade 40 etc
Origin
CHINA (Mainland)
Certificate
ISO9001,ISO14001,OHSAS18001,SGS,BV,SNI
Surface Treatment
Chromated ,Skin Pass,Dry,Unoiled
Thickness
0.13mm~1.5mm
Width
600mm~1250mm According to customers' requirement
Tolerance
Thickness:+/-0.01mm;Width:+/-2mm
Zinc Coating Weight
20~180g/m2
Color Options
RAL Color System or as customer's color sample
Coil Weight
3~5MT or as customer's requested
Application
Industrial and civil construction ,steel structure buildings and producing roofing sheets
Spangle
No spangle
Hardness
Soft or Full Hard or as customer's requested
Packing
Standard Export Packing
Payment Term
T/T OR L/C
Trade Term
FOB/CFR/CIF/EXW
Delivery Time
Around 15 working days -20 working days after receiving deposit by T/T or copy of L/C

MTC of pre painted galvanized steel coil

COMMODITY: PRE-PAINTED ZINC STEEL SHEET Contract NO. HYEXP2010-07-10A Date: SEPTEMBER-17-2010
Steel Grade: ACC JIS G3312, SOFT MATT Condition of Supply PRE-PAINTED ZINC STEEL SHEET
Certificate NO.		 100710A
No. Heat No. Size(mm) Zinc Coating: Color side A Coat property Steel property
Pain thick (μm) T-Bend (T) Impact (J) Gloss (GU) Pencil hard YS. Re Mpa UTS. Rm Mpa EL. A %
1 0710225 0.30X800 MM RAL5012 Z-60 RAL 5012/25 microns 25 3 9 50 3H 360 380 35
2 0710296 0.30X800 MM RAL8004 Z-60 RAL 8004/25 microns 25 3 9 55 3H 365 373 37
3 0710246 0.25X800 MM RAL5012 Z-60 RAL 5012/25 microns 25 3 9 50 3H 358 375 36
4 0710288 0.25X800 MM RAL8004 Z-60 RAL 8004/25 microns 25 3 9 55 3H 355 368 36

Application of Pre Painted Aluminum Coil:
1. Construction:roof for steel structure workshop,airport,storeroom
2. Shipbuilding industry
3. Vehicle manufacturing
4. Furniture industry
5. Electric industry etc.

Product Picture
