Heavy Duty Aluminum Expanded Metal Mesh Sheet panels For Driveway Floor Walkway Steps
Heavy Duty Aluminum Expanded Metal Mesh Sheet panels For Driveway Floor Walkway Steps
Heavy Duty Aluminum Expanded Metal Mesh Sheet panels For Driveway Floor Walkway Steps
Heavy Duty Aluminum Expanded Metal Mesh Sheet panels For Driveway Floor Walkway Steps
Heavy Duty Aluminum Expanded Metal Mesh Sheet panels For Driveway Floor Walkway Steps
Heavy Duty Aluminum Expanded Metal Mesh Sheet panels For Driveway Floor Walkway Steps
Specifications
Brand Name :
YINGHANG
Model Number :
3"-4"
Certification :
SGS
Place of Origin :
CHINA
MOQ :
500 rolls
Price :
according size
Payment Terms :
L/C, T/T
Supply Ability :
1000rolls one week
Delivery Time :
20 days
Packaging Details :
Standard export package or customized
Products Name :
Heavy Duty Expanded Metal Mesh Sheet Driveway Floor Walkway Steps
Key Words :
Expanded Metal Mesh Sheet
Material :
Galvanized Steel Wire,Aluminum sheet,galvanized plate
Strand Thickness :
0.5mm-12mm
Type :
Expanded Mesh,Flattened and Standard
Strand Width :
0.8mm-8mm
Features :
Durable, Corrosion Resistant, Lightweight
Application :
Filters,Fencing
Color :
Silver,red,Black,yellow
Technique :
Perforated
Description

Heavy Duty Expanded Metal Mesh Sheet Driveway Floor Walkway Steps

The expanded metal mesh is widely used for civil construction, cement pouring, machinery and equipment protection, artware manufacture, high-grade speaker net hoods. It is also be used as reinforcement in the construction industry, roads and bridges. Expanded metal mesh can also be used as fence for sports places and road greening belt. Heavy expanded metal mesh can be used for oil tank truck pedal nets, heavy machinery, as well as the working platforms, staircases and walkways of boilers, locomotives, 10,000-ton ships, etc.

Expanded Metal Mesh Specification:

Material Aluminum, Mild Steel, Galvanzied, Stainless Steel and so on.
Technics After stamping and stretching, the metal plate processed into expanded mesh
Shape of hole Diamond
SWD 0.3mm-50mm
LWD 0.5mm-100mm
Thickness 0.02mm-4mm

Features

1.Slit and expand technology make the material without wasting and it can add strength and rigidity to the micro expanded metal.

2.One piece structure will not ravel under normal circumstances.

3.Excellent physical and chemical properties for specific applications, including lightning strike protection, EMI/RFI shielding, acoustic applications.

4.Micro expanded metal can be manufactured from various alloy materials, including stainless steel, titanium, aluminum, silver, copper, brass, nickel and other alloy materials for different applications.

5.Micro expanded metal is available in a variety of 2D and 3D designs including hexagonal, round, diamond and square patterns.

6.Open areas of fine expanded metal are flexible to increase and decrease through specialized manufacturing method.

7.Good electric conductivity.
Application

1. Shielding,chimney caps, animal guards, and other projects that are decorative,

2. Faraday Cages, electronics, aerospace, composite structures, wind energy and more

3. floor heating, ceiling tiles, infrastructure, food services, batteries, glass, jewelry and architectural screens and enclosures.

Thickness (mm) SWD (mm) LWD (mm) Strand (mm) Width (m) Length (m) Weight (kg/m2)
0.5 2.5 4.5 0.5 0.5 1 1.8
0.5 10 25 0.5 0.6 2 0.73
0.6 10 25 1 0.6 2 1
0.8 10 25 1 0.6 2 1.25
1 10 25 1.1 0.6 2 1.77
1 15 40 1.5 2 4 1.85
1.2 10 25 1.1 2 4 2.21
1.2 15 40 1.5 2 4 2.3
1.5 15 40 1.5 1.8 4 2.77
1.5 23 60 2.6 2 3.6 2.77
2 18 50 2.1 2 4 3.69
2 22 60 2.6 2 4 3.69
3 40 80 3.8 2 4 5.00
4 50 100 4 2 2 11.15
4.5 50 100 5 2 2.7 11.15
5 50 100 5 1.4 2.6 12.39
6 50 100 6 2 2.5 17.35
8 50 100 8 2 2.1 28.26

The Term Of Expanded Metal Mesh:

  • SWD (Short Way of the Diamond) is the distance from the middle of the bond on one side to the middle of the bond on the opposite side.
  • LWD (Long Way of the Diamond) is the distance across the largest dimension of the diamond measured halfway between the diamonds.
  • SWO (Short Way of the Opening) is the width of the opening of the shortest side of the diamond. SWO does not include the strand width, where SWD (Short Way of the Diamond) does.
  • LWO (Long Way of the Opening) is the length of the opening of the longest side of the diamond. LWO does not include the strand width, where LWD (Long Way of the Diamond) does.
  • Strand and Bond Expanded metal is composed of strands and bonds. Strands form the sides of the expanded metal openings. Bonds are where the strands intersect. In other words, the bond is where each diamond shaped opening is connected with the next opening.
  • Thickness is the measurement from the top surface to bottom surface of the expanded metal piece.
  • Expanded metal Roll: that the specific length and width of the wound into the roll of steel mesh.
  • Expanded metal sheet: The expanded metal that show specific length and width.​​​
