Blue LC PC APC 2.0MM DX UPC APC Fiber Connector For Patch Cord Cable LSZH PVC
Blue LC PC APC 2.0MM DX UPC APC Fiber Connector For Patch Cord Cable LSZH PVC
Specifications
Brand Name :
HICORPWELL
Model Number :
LC PC 2.0MM DX Connectors
Certification :
IEC 60794-2-10/11
Place of Origin :
China
MOQ :
10sets
Price :
negotiation
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
5000pcs Per Week
Packaging Details :
Max 100m/ per reel for 5.0 mm OD cable
Form Factors :
Duplex/ Simplex
Connectors :
LC PC 2.0MM DX Connectors
Paintcoat Color :
Blue and Green
Cable Diameters :
0.9mm/ 2.0mm/ 3.0mm
Application :
Outdoor Indoor Communication
Fiber Type :
Single mode/ Multimode
End Face Type :
PC/UPC/APC
Jacket Material :
LSZH/ PVC
Connector Type :
SC/LC/FC/ST/MPO/MTRJ/E2000
Description

LC APC 2.0MM DX Connectors for Patch Cord Cable Fiber Optic Components

Fiber optic connectors are ultra reliable components featuring low insertion loss and return loss.They come with your choice of simplex or duplex cable configuration and are made to conform to IEC,

Telcordia GR-326-CORE Standard.

1. Features:

  • Low insertion loss and back reflection loss
  • Ferrule end surface pre-domed
  • Precision anti-rotation key and corrosion resistant body
  • UL-rated plastic housing
  • Telcordia style boots
  • Free-floating ceramic ferrule

2. Applications:

  • Fiber Optic Telecommunications
  • LAN (Local Area Network)
  • FTTH (Fiber To The Home)
  • CATV&CCTV
  • High speed transmission systems
  • Fiber optic sensing

3. Specification:

Single mode Multimode
Insertion Loss <0.10dB <0.20dB
Return Loss ≥55dB(PC)
≥65dB(APC)
Durability <0.2dB typical change,
500 matings
Operating Temperature -40 to +150 -40 to +150
Ferrule Hole Sizes 125.0+1/-0um,
Conentricity:≤1um		 127um,Conectricity:≤3um
125.5+1/-0um,
Conentricity:≤1um
4. Order Choice:
LC/PC SM one-piece, multi-piece, 3mm , 2mm or 900um boot
LC/PC SM duplex with clip
LC/APC SM one-piece, multi-piece, 3mm or 2mm boot
LC/APC SM duplex with clip
LC/PC MM one-piece, multipiece, 3mm , 2mm or 900um boot
LC/PC MM duplex with clip
