GJFJV-02 0.9 Distribution Tight Buffer Glass Fiber Optic Pigtail SC UPC 1M Length
GJFJV-02 0.9 Distribution Tight Buffer Glass Fiber Optic Pigtail SC UPC 1M Length
Specifications
Brand Name :
HICORPWELL
Model Number :
SC UPC Pigtail 0.9 mm Tight buffer Cable
Certification :
IEC 60794-2-10/11
Place of Origin :
China
MOQ :
20 pcs
Price :
negotiation
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
10000pcs Per Week
Packaging Details :
500 pcs per carton
Fiber Type :
G657 or G652D
Connectors :
Customized
Paintcoat Color :
Black or White or others
Cable Purpose :
Indoor Cable Usage
Cable Dia :
0.9mm
Application :
Indoor Communication
Keywords :
SC UPC Pigtail 0.9 mm Tight buffer Cable
Normal Length :
1M/1.5m/3M
Description

SC UPC 1M Length GJFJV-02 0.9 Distribution tight buffer Glass FIber Optic Pigtail

8.2 um Core Diameter, 125 um Cladding Diameter, 250 um Primary Buffer Diameter,

900 um Secondary Buffer, Total Outside Diameter, 0.14 Numerical Aperture,

less than 0.18 dB/km Attenuation at 1550 nm,

less than 18 ps/(nm-km) Dispersion at 1550 nm,

and -82 dB Rayleigh Backscatter Coefficient (for 1 ns Pulse-Width) at 1550 nm Wavelength.

Application: Characteristics:


☆.Components for various indoor cables. ☆.Soft. Easy to strip.


☆.Suitable for patch cords and pigtails. ☆.High quality tight buffered or Loose tube.


☆.Suitable for communication equipment ☆.Excellent mechanical and environmental performance.


served. ☆.Small cable volume. Ling weight.


Denominate:

GJ: Indoor cable


F: Non-metal central strength member


J: Tight buffer


V: pvc or lszh out sheath


Optical Characteristics


Fiber Sort Multimode G.651 A1a:50/125 Graded-index fiber A1b:50/126


Singlemode G.652(A,B,C,D) B1.1:Conventional fiber


G.653 B2: Zero dispersion shifted


G.654 B1.2 :Cut-off wavelength shifted


G.655 B4: Main technical data for positive


dispersion shifted single-mode fiber
