Metal Utp Ftp Stp Patch Cord Molded Boot Per Meter 1.5M 2M 3M 5M 30M Computer Lan Internet Cable
Metal Utp Ftp Stp Patch Cord Molded Boot Per Meter 1.5M 2M 3M 5M 30M Computer Lan Internet Cable
Metal Utp Ftp Stp Patch Cord Molded Boot Per Meter 1.5M 2M 3M 5M 30M Computer Lan Internet Cable
Metal Utp Ftp Stp Patch Cord Molded Boot Per Meter 1.5M 2M 3M 5M 30M Computer Lan Internet Cable
Metal Utp Ftp Stp Patch Cord Molded Boot Per Meter 1.5M 2M 3M 5M 30M Computer Lan Internet Cable
Metal Utp Ftp Stp Patch Cord Molded Boot Per Meter 1.5M 2M 3M 5M 30M Computer Lan Internet Cable
Specifications
Brand Name :
HICORPWELL
Model Number :
Cat5e Cat6 Cat6a Cat7 Lan Cable
Certification :
IEC 60794-2-10/11
Place of Origin :
China
MOQ :
30 roll
Price :
negotiation
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
500 Rolls Per Week
Packaging Details :
305 meters each roll
Cable Type :
Cat 5 Network Ethernet Lan Cable
Paintcoat Color :
Black or Orange or others
MOQ :
30 roll
Roll Length :
305 m
Material :
CCA,BC Copper
Test :
Pass Fluke Test
Number of Conductors :
8
Jacket material :
PVC, ROHS PVC, LSZH PVC
Description

Metal Utp/Ftp/Stp/Sftp Cat5/Cat5E/Cat6/Cat7 Patch Cord Molded Boot Per Meter 1.5M 2M 3M 5M 30M Computer Lan Internet Cable

Specifications

1, Bare copper conductor
2, 8P8C/RJ45/Golden-plated connector
3, OEM different color and length for cat5 patch cord

Category Cat5 cable
Structure Type UTP
Conductor Bare copper/CCAG
Pair 4 pairs
Awg 23awg/24AWG/26AWG/28AWG
Solid/Stranded Stranded
Insulation Material Color-coded PE
Outer Jacket Material PVC/ROHS
Color by customized order
Length by customized order
Reference Standard Category 5 UL444, ANSI/TIA/EIA 568B & ISO/IEC 11801 Standard
Rated Temperature -20° to +75°
Supports transmission Digital and analogue voice, data and video signal
Price we can offer the more competitive price
Quality Toppest raw material conductor, skilled workers to provide good quality products

Specification

Frequency Return Loss Min Attenuation Max

NEXT

Min

PSNEXT

Min

ELFEXT

Min

PSELFEXT

Min
(MHz) (dB) (dB/100m) (dB/100m) (dB/100m) (dB/100m) (dB/100m)
1 20 1.84 74.3 72.3 68 65
4 23.01 3.69 65.27 63.27 55.96 52.96
10 25 5.89 59.3 57.3 48 45
16 25 7.51 56.24 54.24 43.92 40.92
20 25 8.43 54.78 52.78 41.98 39.98
31.25 23.64 10.64 51.88 49.88 38.1 35.1
62.5 21.54 15.36 47.36 45.36 32.08 29.08
100 20.11 19.78 44.3 42.3 28 25
200 18 28.97 39.78 37.78 21.98 18.98
250 17.32 32.84 38.33 36.33 20.04

17.04
Cat5e UTP FTP SFTP Cable
Conductor material CCA,BC Copper
Conductor diameter Solid one: 0.4mm, 0.45mm, 0.5mm
Stranded one: 24 AWG, 26 AWG, 28 AWG
Num of Conductor 2P, 4P, 8P, 10P, 25P, 50P, 100P, 200P ,,,,,
Insulation material PE , HDPE
Insulation diameter 0.9±0.02mm
Jacket material PVC, ROHS PVC, LSZH PVC
Cat6 /cat6a/cat7 UTP FTP SFTP Cable
Conductor material CCA,BC Copper
Conductor diameter Solid one: 0.5mm, 0.56mm, 0.57mm
Stranded one: 23AWG, 24 AWG
Num of Conductor

2P, 4P, 8P, 10P, 25P, 50P, 100P, 200P ,,,,,
Insulation material PE , HDPE
Insulation diameter 0.9±0.02mm
Jacket material PVC, ROHS PVC, LSZH PVC
