High-performance HCW 1200/1320/1600 NA 0.22 Optec fibers high-quality specialty optical fiber
High-performance HCW 1200/1320/1600 NA 0.22 Optec fibers high-quality specialty optical fiber
High-performance HCW 1200/1320/1600 NA 0.22 Optec fibers high-quality specialty optical fiber
High-performance HCW 1200/1320/1600 NA 0.22 Optec fibers high-quality specialty optical fiber
High-performance HCW 1200/1320/1600 NA 0.22 Optec fibers high-quality specialty optical fiber
High-performance HCW 1200/1320/1600 NA 0.22 Optec fibers high-quality specialty optical fiber
High-performance HCW 1200/1320/1600 NA 0.22 Optec fibers high-quality specialty optical fiber
High-performance HCW 1200/1320/1600 NA 0.22 Optec fibers high-quality specialty optical fiber
Specifications
Brand Name :
Hicorpwell
Model Number :
HCW 1500/1650/920/1850/2200 NA 0.22
Certification :
CE & Rohs
Place of Origin :
Guangdong China
MOQ :
10M
Payment Terms :
TT/Westunion
Supply Ability :
5000KM per Month
Delivery Time :
12
Packaging Details :
45*40*38
Fiber Range :
HCW 1500/1650/920/1850/2200 NA 0.22
Packing Size :
28*20*8cm
Coating Diameter :
1650um+-15um
Core Absorption @1530nm (dB/m) :
1500um+-15um
Cladding Diameter :
2200um+-8um
Inner Cladding （N.A） :
>=0.22
Description

Product Description:

This kind of fiber has a step refractive index distribution, the core is made of low hydroxyl quartz,
and has excellent transmission performance in the VIS-NIR band, which can satisfy the application of high power laser
transmission, and also has the advantage of infrared spectral application.
Application environment
Medical applications: Minimally invasive surgery, wound closure
Laser applications: laser transmission, laser welding, laser cutting, laser coupling, laser diode pigtails.
Spectroscopy applications: spectral detection
Other applications: lighting, sensors
Product Characteristics
Spectral range of 200-2200nm
Excellent transmission performance in VIS-NIR band
Hydroxyl content <0.7ppm
Large core diameter
Good flexibility and mechanical strength
Hicorpwell special large core diameter fibers:
This special large core diameter fibers have a silica core, a hard polymer cladding and ETFE coating. Their large core diameter and high NA (0.37) provide efficient coupling to laser sources but even though HCW fibers are able of handling high power, all silica fibers will be more dedicated to high power applications.

Its construction with specific polymer cladding allows a high tensile strength, a very good flexibility and small bend radius to
reach the desired location in the patient’s body. Besides its design is a very cost effective. Because of the exceptional
mechanical performance it is possible to use low cost devices and connectors (“One Shot SMA”) as well as easy termination
procedure for disposable probes.

Technical Parameters:

Product Name HCW-1200-1320-1600-22 Bare Optical Fiber
Wavelength 1530---1625nm
Core Diameter 1200um +-24um
Coating Diameter 1326um+-26um
Core(N.A) 0.22-0.01
Working Temperature -40~85 ℃
[mm](Bend radius) (long term):≥120×(120*Cladding); (momentary):≥60×(60*Cladding)
Core Material Pure fused silica (low OH-)
Coating Material Acrylate coating
Cladding Material Fluorine doped fused silica

Applications:

Some of the major areas where this type of fiber is commonly used include:

1. Materials processing: * Laser cutting, welding, and marking of metals, plastics, and other materials
* Additive manufacturing (3D printing) using laser-based techniques
* Micro-machining and precision drilling
2. Telecommunications: * High-power fiber amplifiers
for long-haul optical fiber communication systems
* Raman amplification in optical fiber networks
3. Scientific and industrial research: * Pump sources for solid-state lasers and nonlinear frequency conversion
* Laser-based spectroscopy and remote sensing applications
* Seed sources for high-energy pulsed lasers
The 30/250μm fiber geometry, combined with Ytterbium doping and the double-clad design, enables the generation

Packing and Shipping:

We use reliable and trusted shipping services to ensure that your Bare Optical Fiber is delivered to you on time and in perfect condition.

The standard shipping method for Bare Optical Fiber is through air freight. This allows for a faster and more efficient delivery process. For international orders, we use air freight services with tracking capabilities to ensure that your package can be traced at any point during its journey. For domestic orders, we offer both standard and expedited shipping options. You can select your preferred shipping method during the checkout process. Once your order has been shipped, you will receive a confirmation email with your tracking number and estimated delivery date.

We take great care in packaging and shipping your Bare Optical Fiber, but in the rare case that your product arrives damaged, please contact us immediately for assistance.

Thank you again for choosing Bare Optical Fiber. We hope you enjoy the product!

FAQ:

  • Q: What is the brand name of this product? A: The brand name of this product is Hicorpwell.
  • Q: What is the model number of this product? A: The model number of this product is HCW-20FB.
  • Q: Where is this product made? A: This product is made in Guangdong, China.
  • Q: What certifications does this product have? A: This product is certified with CE and Rohs.
  • Q: What is the minimum order quantity for this product? A: The minimum order quantity for this product is 2.
  • Q: How is this product packaged? A: This product is packaged with dimensions of 45*40*38.
  • Q: What is the delivery time for this product? A: The delivery time for this product is 12 days.
  • Q: What are the payment terms for this product? A: The payment terms for this product are TT (Telegraphic Transfer) or Westunion.
  • Q: What is the supply ability for this product? A: The supply ability for this product is 5000KM per month.
