Soda Ash Silica Sand ISO9001 380V Glass Batch Plant
Soda Ash Silica Sand ISO9001 380V Glass Batch Plant
Soda Ash Silica Sand ISO9001 380V Glass Batch Plant
Soda Ash Silica Sand ISO9001 380V Glass Batch Plant
Specifications
Brand Name :
JEFFER
Model Number :
Customized
Certification :
ISO9001, ISO14001, ISO45001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1 set per 2 months
Delivery Time :
60 days after received the down payemnt
Packaging Details :
Wooden case, steel frame, tray......
Application :
Glass industry
Treated raw materials :
Silica sand, soda ash, limestone....
Condition :
New
Place of origin :
China
Voltage :
380V
Mixer volume :
Accordingly
Warranty :
1 year
Motor power :
Accordingly
Material :
Mild steel
After-sales service :
Engineer oversea service available
Description

Material Batching, Glass Batch Plant, Material Treatment for Glass

1. Brief introduction

The materials used for glass making are called glass raw materials. Based on the different quantities and functions, the materials are divided into main raw materials and auxiliary ones.

2. Main type of raw materials

Item Description
1 Silica sand
2 Feldspar
3 Dolomite
4 Limestone
5 Soda ash

3. Types of auxiliary materials

The auxiliary materials help the glass to obtain a certain character and increase the melting speed.

Item Description
1 Clarifying agent
2 Decolorizing agent
3 Coloring agent
4 Oxidizing agent
5 Cosolvent agent
6 Reducing agent

4. Arrangmment type of batch plant

  • In-Line type

Silos arrange on one line.
The materials convey to mixer by belt conveyor after discharge from the scale hopper.

  • Tower-type​

Mixer, scales and silos are vertically arranged.
The scales are connected with the mixer directly.

5. Material feeding device

  • Hopper
  • Pneumatic hammer
  • Sensors
  • Material discharging device
  • Instrument and control system

6. Material collecting device

  • Mixer
  • Conveyor device for batch plant

7. Raw mateirals pretreatment

In order to improve the production efficiency, if the granularity composition of raw materials can not meet the physical-chemical properties and processing property of glass product, the raw materials will be required to be pretreated before batching.
