Natural Gas Diesel Oil ISO9001 380V Cross Fired Glass Furnace
Natural Gas Diesel Oil ISO9001 380V Cross Fired Glass Furnace
Natural Gas Diesel Oil ISO9001 380V Cross Fired Glass Furnace
Natural Gas Diesel Oil ISO9001 380V Cross Fired Glass Furnace
Specifications
Brand Name :
JEFFER
Model Number :
Customized
Certification :
ISO9001, ISO14001, ISO45001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1 set per 6 month
Delivery Time :
180 days after received the down payment
Packaging Details :
Wooden case, steel frame
Condition :
New
Voltage :
380V, 50Hz
Dimension :
Customized
Application :
Glass industry
Products :
Domestic glass
Waranty :
One year
Type :
Cross fired furnace
Fuel type :
Natural gas & Diesel oil
Color :
Customized
After-sales :
Engineers available to service machinery overseas
Description

Natural Gas & Diesel Oil, Glass Furnace, Cross Fired Furance For Glass Industry

1. Brief Introduction

Glass is a special amorphous inorganic nonmetallic material. The main component is silicate, a non-crystalline solid with an irregular structure.

Glass was used for windows and doors by the Ancient Romans as early as the 4th century.

The direction of flames of a cross fired furnace is from one side to the other side, which is across the width of the furnace and perpendicular with the flow direction of glass liquid.

The components of batched materials will produce a physicochemical solid phase reaction during heating process, in which the gaseous products will be released from the batched materials and produce a new opacity sinter ultimately, which is formed by silicate and SiO2.

Natural Gas Diesel Oil ISO9001 380V Cross Fired Glass Furnace

2. Factors that influence the melting effects

1 Characteristic of raw materials
2 Chemical compon
3 Material feeding method
4 Melting temperature

3. Process

1 The batching materials go into the furnace
2 The solid materials melt into glass liquid
3 The glass liquid goes into throat after clearing, homogenization and cooling.

4. Main component

  • Melting tank

The melting tank is combined with melting area and clearing area.

  • Regenerator

The regenerator as a waste heat recovery device, the combustion air flows through the regenerator, after preheated, it will arrive at the furnace through the port.

  • Port

It is the place where the fuel is mixed with the preheated air, also an access for the preheated air in to the furnace and exhausting the

waste gas out.

  • Throat

Throat is a core section of the furnace, it will affect the quality of glass and furnace campaign. The temperature of glass will reduce when flowing through the throat.
