Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly
Specifications
Brand Name :
UNIFORM
Model Number :
AUTC-GP
Certification :
RoHS, ISO9001, CE, TUV
Place of Origin :
CHINA
MOQ :
100pcs
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
500pcs/day
Delivery Time :
30 days
Packaging Details :
carton box and wooden box
material :
clean glass
Size :
dia.2.6mm, length:80mm
Angles :
172.9°，151.6°，105.8°
Transmittance :
95%
Shape :
bend shape
HS Code :
9001909090
Description

Medical instrument subassembly Dia. 2.6mm Bend Glass Light Guide Rod for LED Light

Specifications:

Products features:

high precision stereoscopic bend

Clear and clean,

High homogeneity

High temperature resistant

High light transmission

Working temperature:

Regular working temperature: 200°C

Items Description
Light Guide Material: clean glass
Diameter: 2.6+/-0.14mm
Length: 85+/-0.1mm
ROC1: infinity
ROC2 infinity
Surface flatness: N/A
Surface quality: 20-10
Parallelism: <3arcmin
Clear Aperture: >90%
Chamfer: protected
Coating: uncoated
Standard: MIL-PRF-13830B

Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly

Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly

Bend Glass Light Guide Rod Dia 2.6mm Medical Instrument Subassembly

FAQ:

1. . Could you send free samples?
Your samples fee will be returned when you plack bulk order.

2.What's the delivery time?
7 days, it is up to your quantity and soecification and our stock. If in stocks, once you make the payment, your products will be sent within 2 days.

5. Can you OEM or ODM?
Yes, we accept all OEM and ODM.
