S size
- Compatible with 100-240V/50-60HZ
|
- Power supply system cabin 6000K/1500LM central lighting, 4000K natural light background lights on both sides
|
- Twin turbine positive pressure fresh air system gun
|
- Infrared response device + manual opening and closing
|
- Double layer 5+5mm laminated glass
|
- Cabin outer dimensions: W1080*D1000*H2326mm cabin
|
- Inner size:W942*D960*H2146mm
|
- Transport packaging size: 2320*580*1265mm
|

The Silent box acoustic rooms offer a diverse range of options designed to meet various work and communication needs:
The Phone Booth is specifically tailored for phone calls, video conferences, or short working sessions. With an interior space of 100 x 100 cm, it's larger than many similar offerings on the market, allowing for the use of an ergonomic chair for enhanced comfort. Standard equipment includes power and media solutions and a height-regulated desktop for sitting or standing positions.
The Meeting Pod is intended to host meetings for either 4 or 6 people. As standard, it comes with power and media solutions and can be further equipped with TV units or monitors for seamless presentations and video conferences.
The Focus Room is designed for concentrated working sessions. Its large glass wall ensures an influx of daylight, while the upholstered wall panels guarantee excellent soundproofing, making the work environment as comfortable as possible. The spacious interior can be furnished with height-adjustable desks and ergonomic chairs for added comfort.
The construction of these acoustic rooms is modular, featuring glass and upholstered walls fixed to aluminum posts. The wall modules are 500 mm or 1000 mm wide, with 60x60mm posts. The glass walls are made of tempered double glazed glass, providing superior sound insulation. The acoustic upholstered walls have high sound absorption and insulation properties, with a thickness of 60 mm and sound-absorbing material on both outer sides and a core to block sound waves. The outer side of the upholstered wall panels can be customized with a unique 3D pattern, with horizontal stripes available as standard. The glass doors are made of 8 mm thick tempered glass with special hinges and acoustic gaskets. The acoustic ceiling includes ventilation and intelligent light that are both soundproofed and operate automatically with a presence sensor. The intelligent light is programmed to adjust power based on external light conditions.



Modules are available with or without an extra floor, and their modular freestanding construction offers full mobility without the need for floor anchoring. They can also be customized with personalized media and power solutions based on client requirements. In Phone Booths, height-adjustable desktops are standard. Available module sizes include the Single Phone Booth module S (1080*1000*2326mm), Twin Phone Booth module M (1600*1375*2326mm) / SL (2300*966*2326mm), Meeting Pod 4.0 (for 4 persons, L size 2300*2785*2326mm), Meeting Pod 6.0 (for 6 persons, XL size 260024872326mm), and more customization sizes are possible.
Overall, the Silent box acoustic rooms offer a flexible and well-equipped solution for various work and communication scenarios, with customizable options to meet specific client needs.
