IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
Specifications
Brand Name :
GH
Model Number :
Ship Towing Winch
Certification :
CCS, BV, ABS, DNV-GL, RMRS, LR, RINA
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300 Sets Per Month
Delivery Time :
5-60 Days
Packaging Details :
Plywood Pallet
Material :
Stainless Steel
Color :
Customized
Load Capacity :
10-1000KN
Working Speed :
9m/min
Description

Marine single drum or double drum towing winch are approved by CCS, BV, ABS, DNV-GL, LR, NK, RMRS, IRS, RINA etc

Towing winch is widely used in tugboat. Single drum, double drums are available.

For double drums, waterfall configuration is the normal selection. The lower drum is used for anchoring, the upper used for towing.

The nominal speed depend on working load of winch, larger load with slower speed.

Usually the speed is around 3-10m/min, the drum capacity is about 500-1500m.

Spooling device is optional.

Electric driven mode is used for smaller towing winch and hydraulic for big winch.

Local control stands and remote control panel are optional.

Emergency release system is required as per class rules..

The rope length and tension display and constant tension are available.

Braking force =working load*3

Bollard pull=HP/10=KN

Nominal pull=bollard pull*1.5

IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch

Model Drum Load (KN) Nominal Speed (m/min) Holding Load (KN) Dia. Of Rope (mm) Rope Capacity (m)
GH-30 30 15 90 16 150
GH-40 40 15 120 18 150
GH-50 50 15 150 20 180
GH-75 75 15 220 26 180
GH-80 80 15 240 26 200
GH-100 100 15 300 28 200
GH-125 125 15 310 30 200
GH-150 150 15 450 32 250
GH-160 160 15 470 32 250
GH-200 200 9.6 590 40 250
GH-250 250 9.6 730 44 250
GH-315 315 7.8 940 52 250
GH-350 350 7.8 1050 54 250
GH-400 400 7.8 1050 56 250

IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch

Towing winches mainly used for oversize concrete construction of steel installation and disassembly of mechanical equipment. The wire rope ordered arrangement. Lifting is safe and reliable. It is suitable for bridge, factory, harbor, wharf etc. Gear reducer driving, Used for hoisting, pulling, drag, compact structure, stable running.

Advantages and main featrues:

1. Top quality with competitive price.

2. Widely used in factory, mining, shipyard or double beam cranes.

3. Compact structure and reasonable design.

4. Easy to install, operate and maintenance.

5. Low noise and good working condition.

IACS Approved 10-100T Marine Electric Hydraulic Boat Towing Winch
