China Golf car 48V5KW motor 48V400-450Ah controller grade abilisty 25%

Specifications

Place of Origin :

CHINA

Brand Name :

TOP GOLF

Certification :

MOQ :

1 PCS

Price :

negotiable

Packaging Details :

Cartoon Package

Delivery Time :

10-15 WORK DAYS

Payment Terms :

L/C, T/T, Western Union

Supply Ability :

10000 PCS

Model Number :

EV.2+2G

Speed :

25mph

Distance Mileage :

68.5mile

Grade ability :

25%

Brake distance :

<3.5

Charging time :

6-8 hours

Weight :

575

Front suspension :

Double A arm

Bumper :

Front steel bumper

Tyre :

22*10-14

Battery :

Lead acid battery/lithium battery

Motor :

4-5kw

Charger :

48V20A

Controller :

48V400-450A

Lighting system :

LED front combination lights (low beam,high beam,turn signals,daytime running lights,position lights )

Description

Electric Golf Cart Customizable Color High-End Upgradeable

Description

Model No.:EV 2+2G
Charger:computer intelligent charger
Motor:48V/4KW
Battery:Chaowei battery,8V*6
Transaxle:12.31:1
Overall Size:2970*1200*1880mm
Ground clearance:170mm
Tread distance:front900/rear1000mm
Net weight:575kg
Loading:4 people

Optional Spare Parts

Speaker, Underbody lighting,side step,front clay basket,seats cover, security light,cargo box, rear canopy, ice box, caddie plate, body cover,
rain cover, sun curtains, sand rake, sand box, speed meter

Performance

Body and Frame
Frame (Chassis)	Welded steel framework, with anti-rust treatment of acid washing, phosphating and electro-coating
Body and Roof	PP plastic front body and rear body; FRP roof
Windshield	Organic plastic windshield, one-piece
Roof supports	Carbon Steel, powder coated
Backrest and Seat	Reborn Sponge, artificial leather + plastic armrest
Floor	Galvanized Steel plate and anti-slip rubber floor mat
Dashboard	Plastic in black, with 4 cup holders, 2 glove storage box, forward/reverse switch, battery capacity indicator, ignition key
Side trim	Aluminum alloy
Sider mirror	2pcs, foldable
Electric System
Lighting system and horn	All LED lights, 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with 20A voltage reducer (converting from 72V to 12V), electric horn.
Backup Buzzer	12V
Charger	Smart charger, input 110V-240V~50Hz-60Hz, output 72V, 20A
Steering, Brake, Transmission and Suspension
Steering System	Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system	Rear wheel mechanical brake, foot activated parking brake
Accelerator	Stepless speed change
Driving mode	Rear axle two stage deceleration, motor direct driving
Rear axle	Integrated, Gear ratio12.49:1
Suspension system	Front and rear plate leaf spring + cylinder hydraulic shock absorber

Packaging & Shipping

1. Delivery date: 15 days for mass producing
2. 1*20'GP fit 8 units.1*40'HQ fit 21 units.
3. Asia: 3-7 days to arrive; Other : 15-30 days to arrive.

Our Service

We provide 12 months warranty to the electric vehicles from the shipping date. We will cover the labor cost for any warranty issue.

Why choose us?

a. Delivery in Time
b. High quality with reasonable price
c. Quick response to all your inquiry for 5 minutes.
d. Provide customers with high quality products and efficient service.
