DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
Specifications
Place of Origin :
Zhejiang, China
Brand Name :
Gomelong
Model Number :
DDSY5558
Display Type :
Digital Only
Phase :
Single Phase
Measuring Energy Range :
0-999999
Accuracy Class :
1.0s or 2.0s
Output Voltage :
230V(±15%)
Operating Temperature :
-40℃-40℃
Dimensions :
15.5cm*11cm*6cm
Color :
black
Display :
LCD
Material :
PC
Type :
STS Prepayment Meter
Rated Current :
5(60)A
Communication :
RS485 Port MODBUS-RTU Protocol
Frequency :
50HZ~60HZ
Certificate :
STS
Name :
single phase 220V energy meter LCD display kwh meter sts keypad
OEM :
Allowed
Packaging Details :
standard packing
Port :
ningbo/shanghai
Supply Ability :
100000 Piece/Pieces per Month
MOQ :
10 Pieces
Price :
$14.00 - $17.00/Pieces
Description
MASS_APP4_1159_BEGIN

DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter

MASS_APP4_1159_END

DDSY5558 Electronic single phase 220V energy meter LCD display kwh meter sts keypad

Product Overviews

DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter

Quick details

DDSY5558is a new type of key pad prepayment meter,Customer purchases energy by the vending network to get a serial number (name as ToKEN),and then use the keypad of meter to enter the TOKEN,The credit data will be entered into the meter,after the TOKEN being accepted,The TOKEN contains 20digits and is encrypted,For purchasing method reason,the meter also named as keypad meter,It comlies with open standard STS.

Features

♦ Payment by 20digits token

♦ Alarm when low energy/overload/fraud

♦ With Rs485and optical communication functions for reading meter and setting parameters

♦ Open terminal cover decetion alarm

Technical Parameters

Specification

DDSY5558

Accuracy

Active

Class1.0

Reactive

/

Voltage

Rated

220/240V

Range

0.9Un~1.1Un

Limit

0.8Un~1.2Un

Frequency

50/60Hz

Current

Range

5(60)A

Starting Current

0.4%Ib

Constant

Active

 400imp/kwh,800imp/kwh,1600imp/kwh

Reactive

\

\

Display

Type

LCD

Digit

6+1

Power Consumption

Voltage Circuit

≤0.8W,10VA

Current Circuit

≤4VA

Communication

Interface

 Optical/Infrared/RS485(Optional)

Protocol

MODBUS,DLT/645,IEC1107

Temperature

Working Temperature

-45℃~+55℃

Storage Temperature

-40℃~+70℃

Humidity

≤90%

Protection

IP54

DDSY5558 Electronic Single Phase 220V Energy Meter LCD Display Prepayment power consumption Meter
