DTSD5558 Best Seller Wireless Smart Electricity Meter GPRS Electronic Revenue Meter

Specifications

Place of Origin :

Zhejiang, China

Brand Name :

GOMELONG

Model Number :

DTSD5558

Display Type :

Digital Only

Phase :

Three Phase

Measuring Energy Range :

0-999999.99 KWh

Accuracy Class :

1.0 or 2.0s

Output Voltage :

3*220V/380V

Operating Temperature :

-40℃-40

Dimensions :

235mm*173.5mm*150.5mm

Color :

Silver

Type :

AC Active Meter

Certificate :

ISO9001

Display :

LCD

Communication :

RS485 Port MODBUS-RTU Protocol

Frequency :

50HZ/60HZ

Standard :

IEC62053-21

Name :

Electronic Revenue Meter

Rated current :

5A/CT

Packaging Details :

Export carton with inner foam box

Port :

Ningbo

Supply Ability :

100000 Piece/Pieces per Month Electronic revenue meter

Price :

$50.00 - $60.00/Pieces

Description

DTSD5558 Best Seller Wireless Smart Electricity Meter GPRS Electronic Revenue Meter

DTSD5558 Best Seller Wireless Smart Electricity Meter GPRS Electronic Revenue Meter

Model DTSD5558 three phase four wire electronic multifunction energy meter is a kind of new style three phase four wire multifunction energy meter. The meter completely accord with relevant technical requirements of class 1 three phase active energy meter stipulated in international standard IEC 62053-21 and class1 three phase reactive energy meter in international standard IEC 62053-23. It can accurately and directly measure50Hz or 60Hz active energy consumption from three phase four wire AC electricity net, This meter has LCD monitors shows the active energy power consumption, and there are far infrared and RS485 communication module in it. It has following features: Good reliability, small volume, light weight, specious nice appearance, convenient installation, etc.

Features

1. Measurement of Import/Export active energy, current energy balance, Instant

voltage/current/power

2. PLC, Rs485, Infrared interface

3. Event record: Cover open detection, Reverse current, Fraud

Multi Tariff Energy Meter

1. History: 12 months Readable by RS485, and 3 month display on screen

2. Real time clock and date, able to resetting via RS485 wire or Infrared by HHU

3. Time-of-use, 4 Tariff, 8 Time Zone, 12 Segments

4. Battery: It is equipped with build-in lithium battery, which could be use for at least 10years.

Multi Function have all function of Multi tariff meter, Extra reactive energy consumption and power

Technical parameters

Specification		DTS5558L	DTS5558
Accuracy	Active	Class1.0	Class1.0
Accuracy	Reactive	Optional	Optional
Voltage	Rated	3x57.7/100V,3x220/380V 3x230/400V,3x240/415V	3x57.7/100V,3x220/380V 3x230/400V,3x240/415V
	Range	0.9Un~1.1Un	0.9Un~1.1Un
	Limit	0.8Un~1.2Un	0.8Un~1.2Un
Frequency		50/60Hz	50/60Hz
Current	Range	1.5(6), 5(30), 10(50), 15(90), 20(100), 5(40), 5(100)A	3x1.5(6), 3x 5(30), 3x 10(50), 3x 15(90), 3x 20(100), 3x 5(40), 3x 5(100)A
Starting Current		0.4%Ib	0.4%Ib
Constant	Active	1600imp/kWh	1600imp/kWh
Constant	Reactive	\	\
Display	Type	LCD	Register
Display	Digit	6+1	6+1
Power Consumption	Voltage Circuit	≤0.8W,10VA	≤0.8W,10VA
Power Consumption	Current Circuit	≤4VA	≤4VA
Communication	Interface	Optical/Infrared/RS485 (Optional)	Optical/Infrared/RS485 (Optional)
Communication	Protocol	MODBUS,DLT/645,IEC1107	MODBUS,DLT/645,IEC1107
Temperature	Working Temperature	-45℃~+55℃	-45℃~+55℃
Temperature	Storage Temperature	-40℃~+70℃	-40℃~+70℃
Humidity		≤90%	≤90%
Protection		IP54	IP54

Dimension&wiring diagram
