Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Three Phase Din Rail Small Power Meter Digital Electric Meter
Specifications
Place of Origin :
Zhejiang, China
Brand Name :
GOMELONG
Model Number :
DTS5558
Display Type :
Analog and Digital
Phase :
Three Phase
Measuring Energy Range :
000000-999999.9Kwh
Accuracy Class :
1.0 or 2.0s
Output Voltage :
3x220/380V
Operating Temperature :
-45℃-+55℃
Dimensions :
125mm*88mm*73mm
Product name :
three phase din rail small power meter digital electric meter scrap
Baud Rate :
300, 600, 1200, 2400, 4800, 9600.
Rated current :
3*30(100)A
Frequency :
50Hz
Constant :
400imp/kWh
Communication :
RS485 Serial Port
Certificate :
ISO9001/CE
Installation :
35mm Din Rail
Standard :
IEC62053-21
OEM :
Allowed
Packaging Details :
30pcs one canton,standard export package
Port :
Ningbo
Supply Ability :
100000 Piece/Pieces per Month
Price :
$40.00 - $50.00/Pieces
Description

three phase din rail small power meter digital electric meter scrap

Product Overviews

Three Phase Din Rail Small Power Meter Digital Electric MeterThree Phase Din Rail Small Power Meter Digital Electric MeterThree Phase Din Rail Small Power Meter Digital Electric MeterThree Phase Din Rail Small Power Meter Digital Electric Meter Three Phase Din Rail Small Power Meter Digital Electric Meter

SpecificationDTS5558-LCDDTS5558-Register
AccuracyActiveClass1.0Class1.0
ReactiveOptionalOptional
VoltageRated3x57.7/100V,3x220/380V3x57.7/100V,3x220/380V
3x230/400V,3x240/415V3x230/400V,3x240/415V
Range0.9Un~1.1Un0.9Un~1.1Un
Limit0.8Un~1.2Un0.8Un~1.2Un
Frequency 50/60Hz50/60Hz
CurrentRange3x1.5(6), 3x 5(30), 3x 10(50),3x1.5(6), 3x 5(30), 3x 10(50),
3x 15(90), 3x 20(100), 3x 5(40), 3x 5(100)A3x 15(90), 3x 20(100), 3x 5(40), 3x 5(100)A
Starting Current 0.4%Ib0.4%Ib
ConstantActive1600imp/kWh1600imp/kWh
Reactive\\
DisplayTypeLCDRegister
Digit6+16+1
Power ConsumptionVoltage Circuit≤0.8W,10VA≤0.8W,10VA
Current Circuit≤4VA≤4VA
CommunicationInterfaceOptical/Infrared/RS485 (Optional)Optical/Infrared/RS485 (Optional)
ProtocolMODBUS,DLT/645,IEC1107MODBUS,DLT/645,IEC1107
TemperatureWorking Temperature-45℃~+55℃-45℃~+55℃
Storage Temperature-40℃~+70℃-40℃~+70℃
Humidity ≤90%≤90%
Protection IP54IP54

Three Phase Din Rail Small Power Meter Digital Electric MeterThree Phase Din Rail Small Power Meter Digital Electric Meter
