Specifications
Place of Origin :
Zhejiang, China
Brand Name :
GOMELONG
Model Number :
DTS5558
Display Type :
Digital Only
Phase :
Three Phase
Measuring Energy Range :
0-999999.99 KWh
Accuracy Class :
1.0
Output Voltage :
230V
Operating Temperature :
-10-50℃
Dimensions :
158*250*68mm
Max current :
30A
Max record time :
9999 hours
Name :
DTS5558 3 Phase Digital PLC Energy Meter 110v For Sale
Type :
Energy Digital Kwh Meter
Display :
8Digits LCD
Communication :
Modbus RTU
Color :
White
Frequency :
50HZ/60HZ
Standard :
IEC62053-21
Packaging Details :
Exporting package
Port :
Ningbo
Supply Ability :
5000 Piece/Pieces per Month
MOQ :
100 Pieces
Price :
$15.00 - $30.00/Pieces
Description

DTS5558 3 Phase Digital PLC Energy Meter 110v For Sale

Product Overviews

China Product DTS5558 3 Phase Digital PLC Energy Meter 110v For Sale

1. General

DTS three phase electronict watt-hour meter adopts micro-electronic technology, it has high precision and low power consumption, the performance can complies with IEC IEC62052 IEC62053.

It adopts large-scale integration (LSI) and surface mounting technology (SMT), the main components use international famous brand, so the meter has high reliability and long service life. The meter case uses fire-resistant ABS material, and the structure of the meter is air-proofed. Single-chip processing system in the module responsible for the data operation.

2. Technical data

Rated Voltage

3×220/380V

Reference frequency

50Hz

Basic Current (Maximum Current)A

3×1.5(6)

3×5(20) ,3×10(40) ,3×15(60) ,3×20(80),3×30(100)

Applicable Standard

IEC62052 IEC62053

Service Lifetime

10 years

Accuracy Class

Class1

Working Temperature

-25℃~+55℃

Starting current

Class 1=0.004Ib; Class 2=0.005Ib.

Starting current(CT)

Class 1=0.002In; Class 2=0.003In

Working Voltage Range

0.9~1.1Un

Power consumption

=2W,5VA

Over voltage protection

6kV

Relative humidity

=95%

3.Outline drawing

4. Diagram

5. Installation

The meter must be connected according to connection diagram curve in the meter. It is required to tighten the screws and well connect the conducting plate in the terminal block.

6. Guarantee

18 months in case that the meter is sealed and right operation.
