Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Specifications
Place of Origin :
Longkou ,Shandong Province, China
Brand Name :
FC
Certification :
CE/ISO9001
Model Number :
FCFPM-90
Capacity(T/days): :
2T/days
MOQ :
1set or mail to lewis@goodeggtraymachine-com.ecer.com
Packaging Details :
Export Standard Package
Delivery Time :
Within 40-60 days
Payment Terms :
T/T
Supply Ability :
100set/year
Plastic Processed :
PE
Application :
Sheet
Screw Design :
Single-screw
Description

Raw material: LDPE, GMS, TAC, Talc, Butane or Natural Gas

Sheet width:800-1600mm

Sheet thickness:0.5-3.0mm
Capacity:2T/day
Certification: CE,ISO9001
Skype:lewis158824208
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
EPE Foam Machine produces closed fine cell Polyethylene foam sheet by our unique designed Screw and Barrel system using Butane, Talc master batch or Powder and Anti-shrinking agent (GMS for short, Surface Active Agent) by accumulated experience and advanced technology.
Feature & applications:
1.PE foam and related products are made from PE resin and it is expanded and formed into shapes by being heated and extruded. And it is easy to be decompounded and environment friendly.
2.Its key function is cushion protecting and warmth reserving.
3.Nowadays it is the most popularly used for modern batch production products, especially export packaging industry, including electronic industry (such as PC computer, laptop, electronic chips and parts, inverter, TV, air conditioner, refrigerator), furniture, glassware, garments, metal parts, etc.
4.Whoever aims at modern packaging and export, he has to use PE foam for the following reasons: Packaging with air bubble film, EPS and plastic film is forbidden in many countries. Paper packaging is so expensive.
5.PE foam products have quite a few varieties: Sheets for direct wrapping and to make bags; PE sheet may be coated with plastic film, craft paper and aluminum foil. It may be laminated (by electricity or LPG flame) into thick blocks. Then cut them to make different containers or frames. PE fruit net is direct for fruit and small matter's wrapping. If you add special molds, you may make different profiles for door hinges and furniture packing.
Advantages:
1.Simplest operation: With die pressure and temperature display.
2.It may do foaming by 100% LPG gas or butane gas, both available.
3.Unique gearbox with water cooling by a specialized giant gearbox supplier to ensure the performance stable even if continuously working for a few days, the cover still don’t become hot.
4.Unique apply screw tandem to ensure good heating, easy operation and easy maintenance. The extruded sheets are of very equal waves or very smooth sheets. Both the screw and cylinder are made of 38CrMoALA steel and nitride. Cooling: cylinder controlled circulation water for cooling with a standby manual water supply system.
5.Independent heating zones with solid relay and PID for temperature control, so the temperatures are well controlled. The actual temperature error is really within +/- 1 degree.

Main Technical Parameters of EPE Foam Sheet Extruder :

Model:

FCFPM-90

FCFPM-105

FCFPM- 120

FCFPM-150

FCFPM-170

Extruder:

90/55

105/55

120/55

150/55

170/55

Screw speed:

r/min

5-45

Foaming Ratio:

10-40

Product width:

mm

800-1600

1000-2000

1000-2000

1000-2000

1000-2000

Product thickness:

mm

0.5-3.0

0.5-5.0

0.8-8.0

1.0-10.0

2.0-15.0

Cooling Method

Air-cooled, water-cooled

Installed Power

kw

90

100

120

150

180

Dimension:

m

20×2.3×2.2

23×2.3×2.2

25×2.3×2.2

30×2.3×2.2

32×2.3×2.2

Weight:

T

6

8

12

15

17
EPE Foam Sheet characteristics
--High resilience and buoyant effect
--Effective insulating capacity
--Low thermal conductivity
--Negligent absorption and water permeability
--Chemical resistance
--Effective and safe to handle in installation application
--Non-toxic and environmental friendly
--Fine round closed-cell cellular structure assures
--Excellent flexibility
--100% Recyclable and Reusable
EPE foam sheet application:
--External cushioning and packing material
--Packing for high-grade goods, industrial electric parts
--Construction material for insulation
--Educational materials
You can know more from video link:
1.EPE Foam Sheet Extrusion Line Working flow:

http://www.youtube.com/watch?v=ibhaPWeYa54
2.EPE Foam Sheet Extrusion Line Working flow:

http://www.youtube.com/watch?v=Qmstlogf_FM
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)
Location fix pacakge EPE Foam Sheet Extrusion Plant(FCFPM-90)

Main Technical Parameters of EPE Foam Sheet Extruder Line:

Model:

FCFPM-90

FCFPM-105

FCFPM- 120

FCFPM-150

FCFPM-170

Extruder:

90/55

105/55

120/55

150/55

170/55

Screw speed:

r/min

5-45

Foaming Ratio:

10-40

Product width:

mm

800-1600

1000-2000

1000-2000

1000-2000

1000-2000

Product thickness:

mm

0.5-3.0

0.5-5.0

0.8-8.0

1.0-10.0

2.0-15.0

Cooling Method

Air-cooled, water-cooled

Installed Power

kw

90

100

120

150

180

Dimension:

m

20×2.3×2.2

23×2.3×2.2

25×2.3×2.2

30×2.3×2.2

32×2.3×2.2

Weight:

T

6

8

12

15

17

Contact:

Mr Lewis

Email:

lewis@goodeggtraymachine-com.ecer.com

Skype:

lewis15863824208

Gtalk:

lewis15863824208@gmail.com

Yahoo Messenger:

lewis15863824208@yahoo.com

Mobile:

+86-15863824208

Website:

http://www.goodeggtraymachine-com.ecer.com

We are the professional manufacturer of Pulp moulding Machine

and EPE Foam Extruder Line etc in Longkou ,Shandong Province, China.
