Professional CATV Optical Transmitter GFS1310F-E 1310nm Optical Transmitter
Professional CATV Optical Transmitter GFS1310F-E 1310nm Optical Transmitter
Professional CATV Optical Transmitter GFS1310F-E 1310nm Optical Transmitter
Professional CATV Optical Transmitter GFS1310F-E 1310nm Optical Transmitter
Specifications
Model Number :
GFS1310F-E
Place of Origin :
Shenzhen, China
MOQ :
1 pc
Payment Terms :
T/T, L/C
Delivery Time :
10-15 working days
Packaging Details :
Standard Carton
Description

Professional CATV Optical Transmitter GFS1310F-E 1310nm Optical Transmitter

● The transmitting modules of this machine adopt the imported DFB laser.
● The internal RF driving amplifier and controlling circuit of this machine can ensure the best C/N.
● The perfect and stable circuit of optic power output and controlling circuit of thermoelectric refrigeration device of laser module assure the user the best quality and stable working for a long time.
● The internal micro-processor software has many functions such as laser monitoring, number display, trouble alarm and on-line management. Once the working parameter of the laser is out of the fixed range, there will be a red light glistening to alarm.
● The RS-232 standard connector makes it is possible to manage on line and monitor in another place.
● The machine adopts 19”standard shelf and it can work with the voltage from 110V to 254V.

Specifications:​

Model

GFS1310F-E

 2 4 6 8 10 12 14 16 18 20 24 26 30 32 36

Optic Power

(mW)

 ≥2 ≥4 ≥6 ≥8 ≥10 ≥12 ≥14 ≥16 ≥18 ≥20 ≥24 ≥26 ≥30 ≥32 ≥36

Optic Power

(dBm)

 3 6 7.8 9 10 10.8 11.5 12 12.3 12.8 13.8 14.1 14.8 15.0 15.6

Optic Wavelength

(nm)

 1290～1310
Fiber Connector FC/APC,SC/APC,SC/UPC (Optional Customer)

Working Bandwidth

(MHz)

 45～1000
Channels 59
CNR (dB) 51
CTB (dBc) ≤-65
CSO (dBc) ≤-60

RF Input Level

(dBμV)

 Not with pre-distortion 78±5
With pre-distortion 83±5
Band Unflatness ≤0.75
Power Consumption (W) ≤30

Power Voltage

(V)

 220V(110～254)

Working Tem.

(℃)

 0～45
Size 19"×15"×1.75"
