YTWL_CA100F Road Ethiopia Vehicle GPS Speed Limiter for Truck Bus Speed Governor
Product Description
Vehicle speed limiter CA100F is intelligent terminal equipment that can realize precise speed limits for vehicles. It is not only a speed limiter but also a GPS Tracker.
The retrieved data shall be in a format that the motor vehicle inspection officer will be able to understand without requiring the services of a speed limiter specialist.
The speed limiting device shall be so designed, constructed, and assembled so as to resist vibrations, corrosion, dust, humidity, petrochemicals, and aging phenomena to which it may be exposed.
No malfunction or unauthorized interference shall result in an increase in engine power above the demanded by the position of the driver's accelerator. The malfunction of the speed limiter devices shall not affect the normal vehicular performance;
2. Technical Parameter:
Content | Specs. |
Dim. | 117*92*31 (mm) |
Weight | 280g |
Network | GSM/GPRS/GPS |
Band | 850/900/1800/1900MHz |
GPS chip | U-Blox |
GSM/GPRS Module | SIM800C |
Bluetooth Module | BT360I |
CPU | STM32F105RBT6 |
Power IC | TD1509-ADJ |
Anti-jamming | Strengthened Anti-jamming |
GPS sensitivity | -159dBm |
GPS accuracy | 5m |
Time To First Fix | Reacquisition 0.1s Cold status 45s Warm status 35s Hot status 1s |
Work Voltage | DC 9V-36V |
Battery | Rechargeable 3.7V / 1000mAh Li-ion battery (Customizable) |
Standby work current | < 40mA |
Storage Temp. | -40°C to +85°C |
Operation Temp. | -20°C to +70°C |
Humidity | 5%--95% non-condensing |
YTWL_CA100F Road Ethiopia Vehicle GPS Speed Limiter for Truck Bus Speed Governor
3. Installation:
1) Product Accessory:
① Power wire
② Executor wire
③ Extension wire
④ Speaker
⑤ GPS Antenna
⑥ GSM Antenna
⑦ SIM Card Slot
⑧ User Manual
YTWL_CA100F Road Ethiopia Vehicle GPS Speed Limiter for Truck Bus Speed Governor
Speed governor or speed limiter is a device designed to limit the speed of vehicles like trucks, school buses, car forklifts,s and so on. Most of the speed governors are fitted because of government regulations.
Nowadays, we are researching and developing the devices as a fleet management tool. With the function of real-time tracking, Geo-fence, and data recorded, the speed limiters are widely adapted by some governments like Kenya, Nigeria, and also some fleet teams. For safety, the school buses and buses team should be installed the devices properly.
Also about the forklift speed limiter, it's a great tool to reduce accidents and discipline the forklift team. With the lower prices but good quality control, the devices will save you a lot of costs in a very short time. For OEM/ODM to customize the functions you like, you can also contact us.
GPS speed limiter supports work with wireless Bluetooth printer. Click the SOS button on the speed limiter, GPS speed limiter shall automatically connect with the speed limiter and start print the last 1 hr data with over speed data included.
Users can connect to the device USB port with a FAT32 format USB disk and download the last 72 hr driving data stored in GPS speed limiter memory. Beep sound when USB is inserted, Long beep sound when data is all downloaded.
