Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
Specifications
Brand Name :
Cartracker
Model Number :
C003-01-4G GPS TRACKER
Certification :
CE ISO9000
Place of Origin :
China
MOQ :
10pcs
Price :
negotiation
Payment Terms :
T/T or western Union or paypal
Supply Ability :
10,000pcs per month
Delivery Time :
1-10 working days after received your payment
Packaging Details :
Packed in carton firstly
Function :
Real Time Tracking
Place of Origin: :
Shenzhen China
Color :
Black
Working humidity :
20%～80%RH
Battery :
Built-in 200mAh
Use :
Automotive
Type :
4G GPS Tracker
Description

Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence

FDD LTE 800/850/900/1800/2100/2600MHz
GPS positioning GPS sensitivity: -162dBm
GPS positioning accuracy: 5 meters (under open conditions)
Speed ​​accuracy: 0.1 m/s
Cold start time: <38 seconds
Warm start time: <32 seconds
Hot start time: <2 seconds
Base station positioning Support base station positioning, positioning accuracy: 10~200 meters
Working current Average current ≈22mA (12vDC) maximum current <100mA (12VDC)
Operating temperature -20~+70℃
Material Engineering plastics
Weight 50G
Network 4G LTE/3G WCDMA /2G GSM
Dim. 90*40*15mm
Storage Temp. -40°C to +85°C
Accuracy 5-20m
Operation Temp. -20°C to +55°C
Humidity 20%--80% non-condensing
Working Voltage 9-100V
CPU MTK6261

Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence

Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence

Parameter

Size 90(L)×40(W)×15(H)mm
Working temperature -20℃～+70℃
Working Voltage DC9-100V
Weight 50g
Built-in Battery 200MAH

Hardware Specification

Location Accouracy 10M
GPS Chip MT6261
FDD-LTE Frequency 800/850/900/1800/2100/2600MHz
GPS antenna Built-in,18*18*4 mm
GPRS Class12 TCP/IP

Software Specification

ACC Detection support
GEO-fence support
Cut power support
Vibration support
Movement support

Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence

Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence

Indicators

Red light - Power Indicator / OBD Work Lights

LED Status Meaning
Flash once in 2 seconds Normal operation / OBD working properly
No light Shutdown / OBD sleep

Yellow indicator light -GSM

LED Status Meaning
Flash once in 2 seconds GSM initialization
Light Always GPRS is normal / already online
No light GSM sleep

Blue LED light -GPS

LED Status Meaning
Flash once in 2 seconds GPS signal searching
Light Always GPS targeted
No light GPS sleep

Proper Use of The Product

Install→Power on→Settings→Register

Installation: GPS antenna should be facing toward the sky, above the mounting location must be no material (such as metal, window film) absorption of electromagnetic waves sheltered place.

Boot: Insert the SIM card correctly, connect the wire according to diagram, then turn on the power.

Setting: Must be done, or can not do other operations, mobile phone owners send text messages to set the owner number and a specific number to the terminal SIM card.

Registration: Registration method is different subject to dealer platforms, please consult your dealer.

Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence

Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence

FAQ

Q:How about the quality of 4g GPS tracker ?
A :We produce every product with good quality materials and fully test three times before shippment. What is more, our quality areapproved by CE RoHS SGS & FCC, IOS9001, BSCI.

Q: Can i have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q: What is the lead time?
A: Sample needs 1 working days, mass production needs 5-15 working days depends on order quantity.

Q: Can I put order with PayPal for a fast shipment?
A: Sure, we support both alibaba online orders and Paypal, T/T, Western Union offline orders. Please contact us for details.

Contactor Details:

whatsapp: +86-13717161241
mobilephone: +86-13717161241
Wechat:+86-13717161241
website:www.gpstrackerlocator.com
