Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker
Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker
Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker
Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker
Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker
Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker
Specifications
Brand Name :
Cartracker
Model Number :
C003-01-4G
Certification :
CE/ROHS/FCC/SGS ISO9000
Place of Origin :
China
MOQ :
10pcs
Price :
negotiation
Payment Terms :
T/T or western Union or paypal
Supply Ability :
10,000pcs per month
Delivery Time :
1-10 working days after received your payment
Packaging Details :
Packed in carton firstly
Function :
Real Time Tracking
Use :
Automotive
Size :
90*40*15MM
Weight :
0.05kg
Battery :
200mAH
Protocol :
GT06
Antenna :
built-in GPS antenna: 18*18*4 mm
Certificate :
ISO CE
Description

Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker

Technical Paremeter:

Detail
Operating voltage DC9-90V
Operating current 22mA@12V
Specifications L90mm*W40mm*H15mm
Positioning mode GPS, LBS and positioning
Positioning error < 10 m
Support WCDMA Yes
Communication TCP
Operating temperature range -20℃～+70℃
Storage temperature range -40℃~+85℃
weight 50g

Main function

1. Remote power off function
2. Real-time positioning function
3. Anti-theft alarm
4. Track playback function
5. Vibration alarm
6. Overspeed alarm
7. Electronic fence function

Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker

Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker

Product Features:

Model GT06
Features Vehicle malfunction diagnostics
Device Dimension 90mm(L)*40mm(W)*15mm(H)
Weight 50g
Quad Band 850/1900/900/1800MHz
GPS Accuracy 5-10m
Voltage Input 9-100v
　 Hot Start<2S(Open Sky)
Positioning Time Warm Start<15S
　 Cold Start<32S(Open Sky)
Tracking Sensitivity -162dBm
GPS chip MTK6261
GSM/GPS Antenna Built-in Design

Place of Origin Shenzhen China
Network GSM/GPRS 850/900/1800/1900MHz
Certificate CE ROHS FCC
Warranty 2years
Function 4G GPS Tracking
Battery 200mAH
Operation System Andorid IOS
GPRS Class12, TCP/IP

Produce Description

GSM GPRS
Geo-sensor Input power
ACC Ignition checking
Built-in battery Cutt off power/fuel
Real time tracking Over speed alarm
Relay supported Platform /APP supported

Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker

Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker

Indicators

1 Red light - Power Indicator / OBD Work Lights

LED Status Meaning
Flash once in 2 seconds Normal operation / OBD working properly
No light Shutdown / OBD sleep


2 Yellow indicator light -GSM
LED Status Meaning
Flash once in 2 seconds GSM initialization
Light Always GPRS is normal / already online
No light GSM sleep


3 Blue LED light -GPS
LED Status Meaning
Flash once in 2 seconds GPS signal searching
Light Always GPS targeted
No light GPS sleep

LIGHT Functions
Red LED Connect DC 9-100V power supply and will light continuously.
The red LED is the power signal,
It is always on when the external DC is connected.
blue LED It is he GSM signal indicator.
It is always on when there is no GSM;
It flashes when GSM is normal;
It flashes quickly when transmitting data.
yellow LED It is the GPS signal indicator:
It is always on when there is no positioning;
It flashes after positioning.

Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker

Mini GPS Tracking Device With Sim Card For Truck With 2G 3G 4G GPS SMS Tracker

Troubleshooting
If the terminal is unable to connect to the background server in the first time
installation, background shows offline, please check the terminal installation
1 Check is the main power connection correct, pay attention not to connect to the
vehicle interior control wire.
2 Is SIM card installed correctly, please refer to the installation instructions.
3 Please check is it power on, the switch at the back cover.
4 Check the LED status, please refer to the indicators instruction.
5 Check whether the GPS has been positioning, if not please go to the open air for the
first time targeting.

FAQ:

Q:Haw can i buy it?
A:We accept T/T,Westem Uniton and Paypl.After we recerive your payment.

Q:Can we put into my motorcycle?
A:Yes,of course!it support DC9-100V voltage input for any vehicles.

Q:Can we use your platform?
A:yes,you can use our platform.And it is free to use.

Q:What is the lead time if we place order to get the parcel?
A:It needs 1-10 working days after received your payment

What is your cell phone number?

My mobile phone number / WhatsApp is +8613717161241. Wechat is 008613717161241
