Specifications
Brand Name :
Cartracker
Model Number :
C003-01-4G
Certification :
CE ISO9000
Place of Origin :
Shenzhen China
MOQ :
10pcs
Price :
negotiation
Payment Terms :
T/T or western Union or paypal
Supply Ability :
10,000pcs per month
Delivery Time :
1-10 working days after received your payment
Packaging Details :
Packed in carton firstly
Placement :
Portable GPS Tracking Device
Function :
ACC ignition checking
Warranty :
2 Years
Model Number: :
C003-01-4G GPS Tracker
GPS Chip :
MTK Chip
Position Accuracy :
5-10m
Use :
Automotive
Working voltage: :
DC9-100V
Description

Mini GPS Tracking free Platform for Car Trucks Motorcycle Anti-theft Vibration Alarm 4G GPS Tracker

Description

Content Specs.
Dim. 90 mm x40 mm x 15 mm
Weight 50g
Network GSM/GPRS/GPS
Band FDD-LTE 800/850/900/1800/2100/2600MHz
GPS chip U-B
GSM module MTK6261
GPS accuracy 10m
GPS locating time Cold start≈38s(Open sky)
Warm start≈32s(Open sky)
Hot start≈2s(Open sky)
Work voltage DC9V-100V
Storage Temp. -40°C to +85°C
Humidity 20%--80%RH

Mini GPS Tracking free Platform for Car Trucks Motorcycle Anti-theft Vibration Alarm 4G GPS Tracker

Mini GPS Tracking free Platform for Car Trucks Motorcycle Anti-theft Vibration Alarm 4G GPS Tracker

Frequency

2G GSM 850MHz,900MHz,1800MHz,1900MHz
3G WCDMA 2100/1900/900/850MHz
4G FDD-LTE 800/850/900/1800/2100/2600MHz

4G Band

Europe / Middle East / Africa / South
Korea / Thailand

EC25-E:

LTE FDD: B1/B3/B5/B7/B8/B20
LTE TDD: B38/B40/B41
WCDMA: B1/B5/B8
GSM: B3/B8
North America EC25-A
EC25-V
LTE FDD: B2/B4/B12
WCDMA: B2/B4/B5
LTE FDD: B4/B13
Australia/New Zealand/Taiwan/Brazil
EC25-AU
LTE FDD: B1/B2*/B3/B4/B5/B7/B8/B28
LTE TDD: B40
WCDMA: B1/B2/B5/B8
GSM: B2/B3/B5/B8
Japan
EC25-J
LTE FDD: B1/B3/B8/B18/B19/B26
LTE TDD: B41
WCDMA: B1/B6/B8/B19

Mini GPS Tracking free Platform for Car Trucks Motorcycle Anti-theft Vibration Alarm 4G GPS Tracker

Mini GPS Tracking free Platform for Car Trucks Motorcycle Anti-theft Vibration Alarm 4G GPS Tracker

Functions:

Remote cut-off (petrol/power) Light and compact
Compel the vehicle to stop by breaking off the fuel connection Small size allowing covert & easy mounting
ACC detection GPS + LBS Positioning
Be aware of the ignition status where you need Allow the location to be pinpointed in real time
Tracked by: SMS, APP, Web voltage range:9-100V
Reports location in real time through different interfaces Voltage adaptation up to 100v

Electric fence.
Electronic fences are usually used for vehicle theft prevention, wind control area protection, and also for customer reception. When the vehicle enters or leaves the area, the device will send out an alarm message so that the owner can know it in time.
Drawing electronic fence.
You can draw the electronic fence freely, you can draw a circle directly with the device as the center, and set the radius freely.
It is also possible to draw a polygonal pattern so that multiple devices can share the electronic fence area.

ACC detection.
After listening to the ACC connection to judge whether the vehicle is started, if the vehicle starts, it will show that ACC is connected.It is often used for illegal start alarms.
ACC line,when the vehicle starts,the ACC line will generate voltage,the GPS tracker can detect the start of the car.
Vehicle start detection.
ACC line, when the vehicle starts, the ACC line will generate voltage, the GPS tracker can detect the start of the car.
In theory, when the vehicle is started, a certain wire on the vehicle changes from a non-electric state to an electric state, and the ACC wire can be connected to this wire.
The ACC line on the device is generally an orange line.

Mini GPS Tracking free Platform for Car Trucks Motorcycle Anti-theft Vibration Alarm 4G GPS Tracker

Mini GPS Tracking free Platform for Car Trucks Motorcycle Anti-theft Vibration Alarm 4G GPS Tracker

Q1: What kind of SIM card do your devices support?
Re: It support global quad band(850/900/1800/1900) SIM card, 2G GSM network, and enable GPRS flow;

Q2: Can i build my own platform, and only use your device?
Re: Yes, of course, you can build your own plaftform, by our offering GPRS protocol, if you want our help to build a independent platform, it will cost technical fee, details you can contact us directly;

Q3: Can i make my own distributor account on your platform?
Re: Yes, you can, if you are a distributor or want to be a distributor, please share all your IMEIs of devices, and then we can
make a distributor account for you, Available to manage your devices.

Q4: Is there phone APP, support Android and IOS system?
Re: yes, you can download the latest app here, www.19gps.net,www.dyegoo.net and it support android and IOS, no Windows OS;

Q5: How about your platform cost?
Re: Free for lifetime;
